Image preview - the first page of the document
>> Download 9079-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
9077, 9077S, 9077SL / 9079 ,9079S
Product
For Models
Description 180mm (7'') / 230mm (9'') Disc Grinders 484mm(19")
CONCEPTION AND MAIN APPLICATIONS B
The above models are the products with high durability
for stone work in professional use.
The benefits are
1. Coil spring on gear sectio for deadening the shock by accidental wheel lock.
2. Enable to change the handle's angle without any tools for employing as A
a cutting machine.
3. Trouble free new soft starter. 76mm (3")
Mod.9077S, 9079S : with soft start feature 146mm (5-3/4")
Mod.9077, 9079 : without soft start feature A:200mm(7-7/8") for 9077, 9077S, 9077SL
Mod.9077SL : Low speed and high torque version of Mod.9077S A:250mm(9-7/8") for 9079, 9079S,
B:43mm(1-11/16") for 9077, 9077S, 9077SL
Specifications B:68mm(2-11/16") for 9079, 9079S,
Model No. Voltage (V) Current(A) Cycle(Hz) Continuous Rating(W) Max. output(W)
Input Output
110 15 1650 800 2600
9077 *110 19 2000 1100 2600
9077S 120 15 50/60 1650 800 2600
9079 220 9.6 2000 1100 3300
9079S 9.2 1100 3300
230 2000
240 8.8 2000 1100 3300
100 15 1430 600 2600
9077SL 120 15 50/60 1650 800 2600
200 7.5 1430 600 2600
*110 : Great Britain
Motor Series commutator motor (S94-50 load)
No Load Speed 9077 (for Mexico) 8100 R/min.
9077, 9077S 7600 R/min.
9079, 9079S, 9077SL 6000 R/min.
Depressed Outer diameter Inner diameter Thickness
center wheel 9077,9077S,9077SL 180 mm 22.23 mm 6 mm
7" 7/8" 1/4"
230 mm 22.23 mm 6 mm
9079, 9079S
9" 7/8" 1/4"
Standard equipment
For Mod.9077, 907S, 9079, 9079S : Lock nut wrench35
For Mod.9077SL : Lock Nut Wrench 35, Depressed Center Wheel 180-36P
Optional accesories
Descr[tions 9077, 907S, 9079, 9079S 9077SL
Inner flange 47 set (Super flange) Yes Yes Yes
Depressed center wheel 180-24P Yes Yes
Depressed center wheel 180-36P Yes Yes
Depressed center wheel 230-24P Yes
Depressed center wheel 230-36P Yes
Inner flange 78 and Outer falnge 78 for cut off wheel Yes Yes
Wire cup brush 110 set Yes Yes Yes
Loop handle Yes Yes Yes
Dust collecting wheel guard Yes Yes Yes
Sanding disc 180 Yes
Diamond wheel 180 and 230 Yes (180mm) Yes (230mm) Yes (180mm)
** Coil spring joint
for deadening shock by accidental wheel lock
during the work, and for prevention of
over tightening of lock nut by starting shock
or by operation under heavy load.
Long life motor
Effective thickness of segment in commutator.
Dust proof armature by coating varnish in zigzag line.
Field protected with tape from the dust.
High sealed gear housing Soft rubber grip
equipped with O rings on
slip free and
bearing box and spindle lock.
comfortable to grip
