Image preview - the first page of the document
9207SPB-TE


>> Download 9207SPB-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
           Models No.            9207SPB
                                                                                                                  New Tool


           Description           180 mm Sander polisher

CONCEPTION AND MAIN APPLICATIONS
This machine has been for export exclusive type
until now, but also selling for domestic is started.
The sander and polisher can be individually used
by the use of 2-speed and the double insulation
structure can conform to both domestic and foreign
regulation.




    Specifications
           Voltage(V)           Current (A)               Frequency (Hz)          Continuous rating input(W)
             100                   6                         50-60                         570

     No load speed                           3800/2000 min.
     Overall length of machine               460 mm
     Weight                                  3.4 kg
     Cord length                             2.5 m


    Standard equipment
                       Names                                 Applications                           Quantity
       1     Sanding disc 180-16                   For grinding and sanding                            2
       2     Sanding disc 180-20                   For grinding and sanding                            2
       3     Sanding disc 180-24                   For grinding and sanding                            2
       4     Sanding disc 180-50                   For grinding and sanding                            2
       5     Sanding disc 180-80                   For grinding and sanding                            2
       6     Wool bonnet 180                       For polishing                                       1
       7     Lock nut wrench 28                    For mounting the rubber pad                         1
       8     Spanner 17                            For mounting the rubber pad                         1


    Optional accessories
       1    Sanding disc 180-30                For grinding and sanding
       2    Sanding disc 180-100               For grinding and sanding
       3    Sanding disc 180-120               For grinding and sanding
       4    Cup wire brush 90                  For grinding and sanding


    Features and benefits
      (1) The double insulation structure provides no concern for getting an electrical shock.
      (2) The 2-speed structure enables to select the most suitable rotation for the sander and polisher, thereby the higher
               working efficiency achieved.


      The standard equipment for the tools shown may differ form country to country
Repair
(1) Replacing of ball bearing 6201LLB inside the bearing box
 a. Disconnect the mounting screws M4x14(4 pieces) on the bearing box.
 b. Separate the bearing box from the gear housing and disconnect the circle clip(shaft)12 mounting the spiral bevel
    gear to remove the spiral bevel gear from the spindle.
 c. Use the hand press to disconnect the spindle from the bearing box, turn the bearing retainer 22-34 in left to take
    away it, and then replace the ball bearing 6201LLB. For assembling, proceed in the reverse orders against said
    procedures.

(2) Replacing of ball bearing 6002LLB at fan side of armature
 a. Disconnect the bearing box and then remove the gear housing from the gear housing cover.
 b. Turn right the bearing retainer 19-33 on the gear housing cover to remove it, remove the circle clip(shaft)15
    holding the ball bearing 6002LLB from the armature shaft, and then disconnect the armature from the gear
    housing cover to replace the ball bearing 6002LLB
