Image preview - the first page of the document
9200Y-TE


>> Download 9200Y-TE documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION
          Models No.              9200Y
                                                                                                               New Tool


          Description             Car Polisher

CONCEPTION AND MAIN APPLICATIONS
With really unique orbital action(slight vibration), this compact
and lightweight car polisher waxes car very smoothly and
evenly without wax spattering and wandering of polisher.
This tool is also ideal for removing stubborn dirt from car body           95mm (3-3/4")
and oil film from windshield. It is operated by car battery.




                                                                                              114mm (4-1/2")




    Specifications
     DC Magnet Motor (12 V)
     Orbits per min.                             7,000 0/min.
     Pad diameter                                100 mm(4")
     Sponge diameter                             125 mm(5")
     Net Weight                                  0.5kg (1.1lbs)

    Standard equipment
     Sponge 125 (2 pcs.), Spatula (for applying wax to sponge), Plastic case (for resting the polisher)


    Optional accessories
     Sponge set

    Features and benefits
      1.Because of orbital action (slight vibration), wax applied to sponge will not spatter during operation.
      2.Compared with waxing by hand, you can perform smoother and more even waxing on car body surface, using this
       car polisher.
      3.Also ideal for removing stubborn dirt from car body and oil film from windshield.
      4.With soft bumper to protcct car body surface from being scratched by the polisher.
      5.Easy, onextouch installing/removing of sponge thanks to Velcro sheet on sponge and pad.
      6.Can be operated easily by either left or right hand because of compact, lightweight and wellxbalanced tool.
      7.With handy plastic case for resting the polisher.




     The standard equipment for the tools shown may differ form country to country
