Image preview - the first page of the document
9218SB-TE


>> Download 9218SB-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
         Models No.             9218SB
                                                                                                          New Tool


         Description            180 mm Sander polisher

CONCEPTION AND MAIN APPLICATIONS
Model 9218SB is individually used by the double insulation
                                                                                            235 mm
structre can conform to foreign regulation equipped with a
1800mm abrasive paper.
                                                                                                75 mm


                                                                         222 mm




    Specifications
         Voltage(V)           Current (A)               Frequency (Hz)       Continuous rating input(W)
           100                   6                         50-60                      570


      No load speed                        4000rpm
       Weight                               2.7 kg
      Cord length                           2.5 m


    Standard equipment
                                             Quantity
             Abrasive Disc 180-16               2
             Abrasive Disc 180-20               2
             Abrasive Disc 180-24               2
             Abrasive Disc 180-50               2
             Abrasive Disc 180-80               2
             Lock nut wrench 28                 1
              Spanner 17                        1



    Optional accessories
              Cup wire brush 110


    Features and benefits
        This double-insulated polisher prevents electric shocks for your safe operations.
        It has solid structure and is easy to use. It promises you stable performance and good durability.
        With the number of revolutions suitable for polishing, this model with high efficiency is good for
        automobiles, furniture, new building materials and plastic products.
        This polisher is compact, light and easy to operate. In add ition, it polishes even curved surfaces
        and projections freely.




     The standard equipment for the tools shown may differ form country to country
