Image preview - the first page of the document
9402-TE


>> Download 9402-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
         Models No.               9402
                                                                                                                   New Tool


         Description             100mm(4") Belt sander

CONCEPTION AND MAIN APPLICATIONS
                                                                                                     374
This new Belt sander has been developed from 9401
into Electric two-speed function.




                                                                                  170
                                                                          180




    Specifications
         Voltage(V)               Current(A)                Frequency(Hz)               Consumed power(W)
           100 V                     12 A                      50-60 Hz                       1140 W


     Belt speed                  (H) 350 m/min.       (L) 300m/min.
     Belt size                   100 x 610 mm
     Weight                      7.3 kg
     Cord Length                 5m

   Standard equipment
     Step
     Carbon plate
     Each type of sanding belt

    Optional accessories
     Steel plate :
     Each type of sanding belt(5 pieces in one set)

    Features and benefits
      1. By the change of high/low speeds, the cutting amount and cutting conditions can be easily controlled.
      2. The sanding chips can be completely removed by the built-in dust collector, thereby enabling the proper
         operation.
      3. The grinding directly under the right angle wall also possible.
      4. Since the gravity center is positioned at the center of the wide base, the flat sanding without making any step is
         possible.




    The standard equipment for the tools shown may differ form country to country
Repair
 Although same as #9401, the lead wire inside the handle has been increased due to the installation of two speed
 switch. Accordingly use care that the lead wires are not locked together in assembling the handle cover.
