Image preview - the first page of the document
9525NB-TE


>> Download 9525NB-TE documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION

                                 9525NB
                                                                                                                                       New Tool

          For Models
          Description            125mm Angle Grinder
                                                                                                                                /8")
                                                                                                                m       (10-1
                                                                                                           256m
CONCEPTION AND MAIN APPLICATIONS
Model 9525NB is the angle grinder designed for accepting 125mm
wheel on the basic of Model 9523NB and its brief benefits are;
*Slimmer body loaded with more endurable new motor (type S55)
*Labyrinth structure seals out the grinded dust from ball bearings




                                                                     111mm (4-3/8")
*Comfortable slide switch



                                                                                                    139
                                                                                                          mm
                                                                                                               (5-1
                                                                                                                      /2")
    Specifications
                                                                                       Continuous Rating(W)
         Voltage(V)           Current(A)           Cycle(Hz)                                                                     Max. Output(W)
                                                                                      Input            Output
             100                  5.7                  50/60                           540               300                            630
             115                  5.0                  50/60                           540               300                            630
             200                  2.9                  50/60                           540               300                            630
             220                  2.6                  50/60                           540               300                            630
             230                  2.5                  50/60                           540               300                            630
             240                  2.4                  50/60                           540               300                            630

       No Load Speed                                                 10000R/min
       Net Weight                                                    1.4kg (3.1lbs)
       Max.capacity: Depressed center wheel                          125(5")x22.3(7/8")x6(1/4")


    Standard       equipment
     Lock Nut Wrench 35
     Depressed Center Wheel 125-24
     Grip 36 Complate


    Optional       accessories
     Deperssed Center Wheel 125-24       Rubber Pad 115        Lock Nut 14-48
     Abrasive Disc 125-24, 30, 50, 80, 100, 120
     Inner Flange 47 Assembly (Super Flange)


    Features       and benefits
     1. Double insulated
     2. See the attached sheets for more information

     The Standard equipment for the tool shown here may differ from country to country.
Slim/trim body 56mm wide
for easy, comfortable gripping thanks to the slim but endurable S55-type motor




                                                                                       More endurable motor
                                                                                      Armoured with special varnish
                                                                                      on armature coil and taping on
                                                                                      field coil for protection against
                                                                                      dust and wire snap


                                                                                        Housing



        Labyrinth structure
                                                                           Armature
       to protect ball bearings from dust




                                                                                           Labyrinth structure




Repair
 Corresponding to 9523NB
