Image preview - the first page of the document
9528NB-TE


>> Download 9528NB-TE documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION

                                      9528NB
                                                                                                                                     New Tool

           For Models
           Description                125mm Angle Grinder                                                               0-1/8
                                                                                                                                ")
                                                                                                                (1
                                                                                                       25   6mm


CONCEPTION AND MAIN APPLICATIONS
Model 9528NB is the 125mm and slide switch version of the new
100/115/125mm angle grinder series and designed for professional
users.




                                                                     111mm (4-3/8")
Its brief benefits are;
*Labyrinth structure seals out the grinded dust from ball bearings
*Slim body loaded with endurable new motor (type S55)
                                                                                                     139
                                                                                                           mm
                                                                                                                (5-1
    Specifications                                                                                                     /2")

                                                                                       Continuous Rating(W)
         Voltage(V)                Current(A)           Cycle(Hz)                                                                Max. Output(W)
                                                                                      Input            Output
               100                      7.9               50/60                        750               420                           850
               115                      6.9               50/60                        750               420                           850
               200                       4                50/60                        750               420                           850
               220                      3.6               50/60                        750               420                           850
               230                      3.4               50/60                        750               420                           850
               240                      3.3               50/60                        750               420                           850

       No Load Speed                                                          11000(rpm)
                                                     U.S.A.                   10000(rpm)
       Net Weight                                                             1.4kg (3.1lbs)
       Cord Length                                                            2.5m(8.2ft)
       Size of depressed center wheel                                         125(5")             X 22.23(7/8")                  X 6(1/4")
                                                                              Outer diameter      Arbor diameter                 Thickness


    Standard         equipment
     Lock Nut Wrench 35(Din-type)......1
     Grip 36 Complate............................1
     Depressed Center Wheel 125-36.....1

    Optional         accessories
     Deperssed Center Wheel 125-36(5pcs./pk)
     Rubber Pad 115
     Lock Nut 14-48
     Abrasive Disc 125-24, 30, 50, 80, 120
     Super Flange(Din-type)
     Diamond Wheel
     Cut-off Wheel

    Features         and benefits
     1. Double insulated
     2. See the attached sheets for more information

     The Standard equipent for the tools shown may differ from country to country.
Extremely quiet(to see the following comparion of no lord noise)
Makita Model 9528NB : 84db
Makita Model N9505BH : 86db

Slim/trim body 56mm wide
for easy, comfortable gripping thanks to the slim but endurable S55-type motor




                                                                                             More endurable motor
                                                                                            Armoured with special varnish
                                                                                            on armature coil and taping on
                                                                                            field coil for protection against
                                                                                            dust and wire snap

                                                                                                  Housing




                                                                                 Armature



                 Labyrinth structure
                to protect ball bearings from dust


                                                                                                     Labyrinth structure




 Repair
  Corresponding to 9526NB
