Image preview - the first page of the document
9522NB-TE


>> Download 9522NB-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.             9522NB
                                                                                                                                     New Tool

                                                                                                                        /8")
        Description                                                                                                 10-3
                               125mm (5") Angle Grinder
                                                                                                            2m
                                                                                                               m(
                                                                                                       26

CONCEPTION AND MAIN APPLICATIONS
125 mm (5") version of Model9520NB.




                                                                  111mm (4-3/8")
                                                                                        12
                                                                                          9m
                                                                                             m
                                                                                                 (5-
                                                                                                    1/2
   Specifications                                                                                      ")


                                                                            Continuous Rating (W)
      Voltage (V)        Current (A)        Cycle (Hz)                                                          Max. Output(W)
                                                                           Input           Output
         100                  7.0              50/60                        670              380                               700
         115                  6.1              50/60                        670              380                               700
         200                  3.5              50/60                        670              380                               700
         220                  3.2              50/60                        670              380                               700
         230                  3.5              50/60                        670              380                               700
         240                  2.9              50/60                        670              380                               700

     Max. capacities( dia.)   Depressed center wheel         125mm(5")
                              Diamond wheel                  125mm(5")
                              Abrasive disc                  125mm(5")
     No load speed                                           12,000R/min.
     Net weight                                              1.3Kg(2.9lbs)


   Standard equipment
     Depressed center wheel 125-24, lock nut wrench 35,Grip 36

   Optional accessories
    Depressed center wheel 125-24, Rubber pad 115, Lock nut 14-48, Abrasive disc 125-24, 125-30, 125-50, 125-80,
    125-120, Inner flange 47 (Super flange)


   Features and benefits
     1. Double insulated
     2. Refer to the attached sheet for more information .




    The standard equipment for the tools shown may differ form country to country
                                     Lock-off, Lock-on slide switch          slim/trim body for easy, com-
                                                                             fortable gripping

     Large shaft lock for easy wheel
     changes




                                                                       Labyrinth construction seals out
                                                                       dust/dirt from bearings.


super flange (optional accessory)
can be installed. Use of the super
flange makes it easy to remove the
grinding wheel after operations.
                                            Side grip can be installed on
                                            either left or right side of
                                            the tool.


                                                                              Armature
                                                                                                             Housing


                                                                               Labyrinth construction
