Image preview - the first page of the document
9609NB-TE


>> Download 9609NB-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.             9609NB
                                                                                                       New Tool


     Description            180/230 mm Disk/Angle grinders

CONCEPT AND MAIN APPLICATIONS
  This unit is the Disk grinder developed as
  the sister versions of #9607B and 9609B,
  and the export exclusive machine for further
  sales expansion in reply to the demands from
  overseas, wherein the body weight has been
  reduced and the double insulation structure
  can conform to the foreign standards.




  Specifications
                                                                                           Continuous rating
                        Voltage (V)              Current (A)              Cycle (Hz)                input (W)
      9607NB                100                      17.5                   50/60                 1650
      9609NB                100                      17.5                   50/60                 1650

                                                      #9607NB                              #9609NB
   No load speed (R.P.M.)               8000 /min.                            6200 /min.
   Depressed center wheel               180 22x6 mm                           230x22x6 mm
   Overall length of machine            413 mm                                413 mm
   Net Weight                           5.0 kg                                5.3 kg
   Power supply cord                    2.5 m                                 2.5 m




  Standard equipment
  Depressed center wheel
  Lock nut wrench 35(Spanner 17 attached unless the stopper is mounted)


  Optional accessories
  Base assembly
  Inner flange 40
  Inner flange 45
  Inner flange 78
  Outer flange 78
  Lock nut 14-48
  Lock nut 16-48
  Cut off wheel 180




  The standard equipment for the tools shown may differ form country to country
Features and benefits
(1) The light weight type enables to handle easily with less fatigue.
(2) The armature can be easily disconnected from the gear housing and also the pinion can be readily removed.(Easy
  disassembling)
(3) The machine can be securely made stable when it is turned upside down to load/unload the wheel.
(4) Double insulated.

Capacity
Compared with the #9607B and 9609B, there is totally a slight difference in capacity. Namely it has almost the same
grinding capacity, but the load current and the temperature are slightly increased.

Repair
Disassembling orders in replacing the armature:
First remove the offset grindstone, wheel cover and carbon brush etc., next remove the pan head screws M5x40 for
mounting the gear housing and motor housing, use the nylon hammer to slightly hammer the protrusion on gear
housing at top and the mounting points at bottom side to expand the clearance between the motor housing and plate,
place the minus driver edge into the expanded clearance, and then use the another two drivers to disconnect the
motor housing in parallel while twisting the drivers. Next use the nylon hammer to hammer evenly the side
faces(protrusion at top and mounting points at bottom) of the gear housing, and then pull out the armature from the
gear housing in a straight line while holding the core at the armature.
Since the rubber pin for preventing from turning is mounted on the housing of ball bearing at front/rear of the
armature, remember to place it.
