Image preview - the first page of the document
9803-TE


>> Download 9803-TE documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION                                                                                     New Tool

          For Models            9803
          Description           T.C.T saw blade sharpener


CONCEPTION AND MAIN APPLICATIONS
Model 9803 with a dry-type diamond wheel is compact and light, but




                                                                                                                        236
promises you accurate grinding.
This model easily enables grinding and polishing of chip saws of
which outer diameter is 120-500mm. This compact grinder has a small




                                                                                          20
but powerful motor, which upgrades its grinding and polishin g




                                                                                            0
capacities, and realizes the polishing capacity equivalent to that of a                                     546
large model. You can operate and use it easily.



    Specifications
                                                                           Continuous rating
         Voltage (V)         Current(A)          Cycle(Hz)                                                   Max. output(W)
                                                                      Input (W)        Output (W)
             100                 2.0                  50/60              190               7.5                    100
             115                 1.7                  50/60              190               7.5                    100
             200                 1.0                  50/60              190               7.5                    100
             220                 0.9                  50/60              190               7.5                    100
             230                 0.9                  50/60              190               7.5                    100
             240                 0.8                  50/60              190               7.5                    100

       Motor                                      Single-phase series commutator motor
       No load speed                              5500/min.
       Net weight                                 11kg
       Power supply cord                          2mm
       Diamond Wheel dimensions
