Image preview - the first page of the document



>> Download 3700B-TE documenatation <<

Text preview - extract from the document

T   ECHNICAL INFORMATION                                                                                         Product

     For Models             3700B
     Description            Trimmer


CONCEPTION AND MAIN APPLICATIONS
Double insulation version of Model 3700, and it provides the operaters
safety work protecting from electrick shock.




                                                                                                                             234mm(9-1/4")
Specifications
  Voltage                          100 V
  Current                             3A
  Cycle (Hz)                    50 - 60 Hz
  Continuous Rating Input          440 W
  No load speed                  28000 rpm.
  Collet capacity                     6 mm or 1/4"

 Standard     equipment
  Trimmer Guide Assembly            1 pc.
  Straight Guide Assembly           1 pc.
  Templet Guide                     1 pc.
  Carbide-Tipped Straight Bit       1 pc.
  Wrenches                          2 pc.
  Collet Cone 6mm or 1/4"           1 pc.


 Optional     accessories
   Sash Router Base Assembly
   Trimmer Shoe
   Trimmre Bits mentioned in our general catalogue

 Features     and benefits
  1. Double insulated constructoin for protection of the operaters from electric shock,
     and plastic motor housing with low thermal conduction provides comfortable work.
  2. Trimmre Giude Assembly with roller provides the smooth guide and protection of the work piece from
     the damages, such as scratch.
  3. Powerfull, however, low noise motor.
  4, Easy to adjust the trimming point, because of smooth moving of motor housing inside of the trimmer base.

 Repair
  1. Mounting of Switch
     Switch has t be mounted with making sure that "ON" - "OFF" positions of switch lever conform to
     the "ON"-"OFF" indication on the motor rear houing.
  2. Dismounting of armature from the motor housing
     After dismounting of collet nut, collet cone and carbon brushes from the armature shaft, take off the amature section
     (including motor rear housing). and then armature can be taken off from the motor rear housing.
     However, do not hit the motor rear housing.
  3. Pay attention that the set screw fastening the guide roller is left-handed one.
