    Models No.               BJR240
                                                                                                                     P 1 /15

    Description              Cordless Recipro Saw

CONCEPTION AND MAIN APPLICATIONS                                                                     L
    The above model has been developed to be added to MAKSTAR
    series models which are featuring New Charging System.
    Other features and benefits are
     * The fastest cutting speed among the cordless recipro saws                                                          H
     * Incredible low vibration with counterbalancing system
       in its gear unit.
     * Tool-less features for easy and rapid changing recipro saw blade                                   W
       and for easy adjusting shoe
    The variations of this model are listed below.
                                                                                Dimensions : mm ( " )
                                             Q'ty of                       Length ( L )               469 (18-1/2)
    Model No.          Battery               Battery      Charger
                                                                           Height ( H )
                                                                                          w /B2430       255 (10)
    BJR240SH         B2417 (1.7Ah)           1 pc.        DC24SA
                                             1 pc.
                                                                                          w /B2417       230 (9)
    BJR240SF         B2430 (3.0Ah)                        DC24SA
                                                                           Width ( W )                    88 (3-1/2)

     Battery        Voltage : V                                                            24
                    Capacity : Ah                            1.7 with Battery B2417             3.0 with Battery B2430
     Length of Stroke                                                                32 mm (1-1/4")
     Strokes per Minute                 High                                         0 - 2,700
              :spm.(min-1)              Low                                          0 - 2,300
     Cutting                           Pipe
