Image preview - the first page of the document
BLS820-TE


>> Download BLS820-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION
      Models No.                     BLS820SF
                                                                                                                                               NEW TOOL
                                                                                                                                                    P 1 / 11

      Description                    Cordless miter saw 216mm (8-1/2")

CONCEPTIONinAND MAIN APPLICATIONS
BLS820SF is included Makita's new line-up of
24V cordless tools powered by our brand-new, 24V
Nickel-Metal Hydride battery.
Taking over the benefits of our existing Model LS800D,
yet, this machine is more powerful thanks to the new 24V battery.                                                                                         H
Ideal for a wide range of interior works.
This model comes with charger DC24SA and
battery B2430 ( 24 V, 3.0Ah).
                                                                                              W
                                               Dimensions : mm ( " )                                                                    L
                                     Length (L)             430 (17)
                                     Width (W)              528 (20-3/4)
                                     Height (H)             486 (19-1/8)

   Specification
              Voltage (V)                              24
      Battery Capacity (Ah)                             3.0
              Energy (Wh)                             72.0
      No load speed : (min -1= rpm)                2,300
                  Diameter : mm ( " )      210 (8-1/4) - 216 (8-1/2)
      Applicable                           15.88 (5/8) for Canada, USA. Mexico
      Blade       Hole diameter : mm ( " ) 30.0 (1-3/16 ) for European countries
                                           25.4 (1)for Other countries
      Net weight : Kg (lbs)                 10.1 (22.3)

      Max. cutting capacity : Height x Width / mm ( " )
                                    Bevel angle
                               0
