Image preview - the first page of the document
BO4540-TE


>> Download BO4540-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.                B04540
                                                                                               New Tool


        Description               Makita Finihing sander

CONCEPTION AND MAIN APPLICATIONS
As a sister model of the current #B04510,
we have developed the less expensive new sander.




    Specifications
                                                              Continuous Rating (W)      Max.
      Voltage (V)      Current (A)         Cycle (Hz)         Input           Output   Output(W)
          100               1.8               50/60            160              8.5       90
          115               1.6               50/60            160              8.5       90
          200               0.9               50/60            160              8.5       90
          220               0.8               50/60            160              8.5       90
          230               0.8               50/60            160              8.5       90
          240               0.7               50/60            160              8.5       90

     No load speed    14000/min
     Pad size         100 x 110


    Standard equipment
       Sanding paper 114-60 -------------------------- 2pcs
       Sanding paper 114-100 ------------------------- 2pcs
       Sanding paper 114-150 ------------------------- 2pcs


    Optional accessories
       Sanding paper 114-60
       Sanding paper 114-100
       Sanding paper 114-150
