T   ECHNICAL INFORMATION                                                                                      New Tool

     Models No.                BO5000

     Description               125 mm(5") Random Orbit Sander

  With its dual rotary and orbital sanding actions, this compact
  and lightweight sander can sand workpieces very fast.


                                                                     Continuous Rating (W)
   Voltage (V)       Current (A)         Cycle (Hz)                                            Max. Output(W)
                                                                    Input          Output
       100               2.0               50/60                     180             100              100
       115               1.7               50/60                     180             100              100
       200               1.0               50/60                     180             100              100
       220               0.9               50/60                     180             100              100
       240               0.8               50/60                     180             100              100

  No Load Speed                                                12,000 O/min
  Max. Capacities (Diameter)       Abrasive disc               125mm (5")
                                   Pad                         123mm (4-7/8")
  Orbit Diameter                                               4mm(5/32")
  Net Weight                                                   1.3Kg(2.9lbs)

 Standard equipment
  Abrasive    disc 125-60, 125-100, 125-150 (2 pcs. each)

 Optional accessories
  Abrsive disc 125-60, 125-100, 125-150, Abrasive disc (with pre-punched holes) 125-60, 125-100, 125-150, Hose
  (for connecting to vacuum cleaner)

 Features and benefits
   1. With its dual rotary and orbital sanding actions, this sander can sand workpieces three times faster than existing
      Model BO4510, BO4540, etc.
   2. Compact, lightweight and comfortable-gripped tool for easy one-hand operation.
   3. Clean sanding operations can be performed by using an optional abrasive disc with pre-punched holes, an
      optional hose and a vacuum cleaner (Makita Mode1s 401, 402, etc.)
   4. Double insulated for operator safety.

  The standard equipment for the tools shown may differ from country to country
