Image preview - the first page of the document
BO5001-TE


>> Download BO5001-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.            BO5001
                                                                                                            New Tool


     Description           Random Orbit Sander

CONCEPTION AND MAIN APPLICATIONS




                                                                               154mm(6-1/16~)
  This is a small and light-weight sander with extremely high
  speed by the function of Random Orbit System
  (Orbital movement + Rotating movement).                                                                              12
                                                                                                            (4               3m
                                                                                                                 -7               m
  The model was made by changing the material and shape of                                                            /8
                                                                                                                         ~   )
  cooling fan of #BO5000.


                                                                                                       m
                                                                                                127m
                                                                                                  ( 5 ")
  Specifications
                                                           Consumed          Rated                Max.
     Voltage(V)       Current(A)       Frequency(Hz)
                                                           power(W)        output(W)            output(W)
         100               2.0              50-60             180             100                  100
         115               1.7              50-60             180             100                  100
         200               1.0              50-60             180             100                  100
         220               0.9              50-60             180             100                  100
         230               0.9              50-60             180             100                  100
         240               0.8              50-60             180             100                  100

    No load speed        No. of Orbiting(/min.)          10000
    Sanding Disk Size(mm)(in.)                           125mm (5") (Velcro Tape Type)
    Pad Size(mm)(in.)                                    123mm (4-7/8")
    Eccentric Volume(mm)(in.)                            2.0mm (3/32")
    Eccentric Diameter(mm)(in.)                          4.0mm (5/32")
    Weight(kg)(lbs)                                      1.3kg(2.9lbs)
    Cord length(m)(ft)                                   2m(6.6ft)


  Standard equipment
  Sanding Disk 125-60, 120, 240----------------Each 2pcs packed (with dust-absorbing hole)


  Optional accessories
  Sanding Disk 125-60,80,120,180,240--------Each 5pcs packed (with dust-absorbing hole)
  Hose Complete 19-2.5 Set Goods-------------Dust collecting machine for connecting #402,405
  Rubber Sleeve18-21-----------------------------Dust collecting machine for connecting #420


  Capacity
  Same as the notice of technology of new product #BO5000 (BL-2074)


  Comparision
  Same as the notice of technology of new product #BO5000 (BL-2074)


  Repair
  Same as the notice of technology of new product #BO5000 (BL-2074)




  The standard equipment for the tools shown may differ from country to country.
