Image preview - the first page of the document
>> Download BO5020-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION New Tool
Models No. BO5020 BO5021
Description Random Orbit Sander
CONCEPTION AND MAIN APPLICATIONS 288mm(11-3/8")
Model BO5020/BO5021are sister versions of the existing
Model BO5010.
Their brief benefits are;
147mm(5-3/4")
*Comfortable operation
by holding both hands.
*Variable speed futuregives wider applications
as sanding and polishing (BO5021 only)
Specifications 123mm(4-7/8")
Continuous Rating (W)
Voltage (V) Current (A) Cycle (Hz) Max. Output(W)
Input Output
100 2.7 50/60 260 100 150
110 2.4 50/60 260 100 150
120 2.0 50/60 220 65 150
220 1.2 50/60 260 100 150
230 1.2 50/60 260 100 150
240 1.1 50/60 260 100 150
12,000 /min(BO5020)
Orbits per minute
4000-12,000 /min(BO5021)
Abrasive disc Diameter: ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
