Image preview - the first page of the document
BO5021-TE


>> Download BO5021-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION                                                                                     New Tool


       Models No.              BO5020        BO5021

       Description             Random Orbit Sander

CONCEPTION AND MAIN APPLICATIONS                                                  288mm(11-3/8")
   Model BO5020/BO5021are sister versions of the existing
   Model BO5010.
   Their brief benefits are;




                                                               147mm(5-3/4")
    *Comfortable operation
     by holding both hands.
    *Variable speed futuregives wider applications
     as sanding and polishing (BO5021 only)




  Specifications                                                               123mm(4-7/8")


                                                                    Continuous Rating (W)
      Voltage (V)        Current (A)       Cycle (Hz)                                              Max. Output(W)
                                                                   Input          Output
          100                2.7              50/60                 260             100                 150
          110                2.4              50/60                 260             100                 150
          120                2.0              50/60                 220             65                  150
          220                1.2              50/60                 260             100                 150
          230                1.2              50/60                 260             100                 150
          240                1.1              50/60                 260             100                 150

                                      12,000 /min(BO5020)
     Orbits per minute
                                 4000-12,000 /min(BO5021)
     Abrasive disc             Diameter:
