Image preview - the first page of the document
BTW150-TE


>> Download BTW150-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
    Models No.
                                 BTD150
                                 BTW150
                                 14.4V Cordless Impact Driver                            BTD150
                                                                                                                          PRODUCT
                                                                                                                            P1/7

    Description                                                                                                          BTW150
                                 14.4V Cordless Impact Wrench
CONCEPTION AND MAIN APPLICATIONS                                                                 L                            L
   The above models are equipped with newly developed battery.
   The brief benefits and features are as mentioned below.
   BTD150 : *Superior to Model 6916D or BTD120 in fastening speed.
              *Slim designed grip for easy and comfortable gripping.
              *Equipped with bumper to protect the materials from scratch.
   BTW150 :*Same max. fastening torque, 150 N.m as Mod.6902D
                                                                                                           H                           H
               but much more compact than Mod.6902D.
              *Slim designed grip for easy and comfortable operation.
              *Equipped with bumper to protect the materials
               from scratch.                                         W                                         W
    Below listed standard type models are only available.
                                                                      Plastic            Dimensions : mm ( " )
     Model No.                   Battery                 Charger      case
                                                                                    Model No.      BTD150                BTW150
                                                                      Yes
     BTD150SA Ni-MH                  DC14SA                                         Length ( L ) 190 (7-1/2)            193 (7-5/8)
              BH1420 / 14.4V / 2.0Ah
                                                                                    Height ( H )  *253 (10)             *253 (10)
     BTW150SA Ni-MH                  DC14SA                              Yes
                                                                                    Width ( W )    78 (3-1/16)           78 (3-1/16)
              BH1420 / 14.4V / 2.0Ah
                                                                                    *253 (10) is the height with battery BH1420.
  Specification
    Model No.                                                  BTD150                                      BTW150
    Voltage (V)                                                 14.4                                          14.4
    No load speed (min-1=rpm)                                 0 - 2,300                                     0 - 2,300
    Impact per minute (min-1=bpm)                             0 - 3,000                                     0 - 3,000
    Driving shank : mm ( " )                                 Hex 6.35 (1/4)                            Square 12.7 (1/2)
                Standard bolt                                                                         M10 - M16 (3/8 - 5/8)
               High Tensile bolt                                                                      M8 - M12 (5/16 - 1/2)
               Machine screw                            M4 - M10 (5/32" - 3/8")
    Capacities
