Image preview - the first page of the document
DA392D-TE


>> Download DA392D-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
    Models No.              DA302D, DA392D, DA312D                                     W
                                                                                                L
                                                                                                           PRODUCT
                                                                                                             P1/6

    Description             7.2 V, 9.6v, 12V Cordless angle drills 10mm (3/8")

CONCEPTION AND MAIN APPLICATIONS                                                  H
                                                                                       W
                                                                                                        DA302D

   The above models are the series of keyless drill chuck type
   cordless angle drills.                                                                       L
   DA302D 7.2V : The succession of the existing Model DA301D.
   DA392D 9.6V : The succession of the existing Model DA392D
                    equipped with pod type battery with push button.              H                     DA392D
   DA312D : 12V version of Model DA392D                                               W
   The variations of these models are as listed below.                                  L
                                Type of
      Model No.       Battery cell        Q'ty Charger
      DA302D      without any battery and charger                          H                  DA312D
     *DA302DW     7000 (1.3Ah) Ni-Cd 1pc. DC9710
     *DA302DWB 7033 (2.2Ah) Ni-MH 1pc. DC9711
      DA392DZ      without any battery and charger
     *DA392DW 9120 (1.3Ah) Ni-Cd 1pc. DC9710                              Dimensions : mm ( " )
     *DA392DWA 9122 (2.0Ah) Ni-Cd 1pc. DC9711              Model No.       DA302D      DA392D     DA312D
     *DA392DWD 9134 (2.6Ah) Ni-MH 1pc. DC9711              Length ( L ) 296 (11-5/8) 324 (12-3/4) 324 (12-3/4)
     *DA392DWF 9135 (3.0Ah) Ni-MH 1pc. DC9711
      DA312DZ       without any battery and charger        Height ( H ) 104 (4-1/8) 104 (4-1/8) 104 (4-1/8)
     *DA312DWA 1222 (2.0Ah) Ni-Cd 1pc. DC1411              Width ( W ) 59 (2-5/16) 77 (3)          94 (3-11/16)
     *DA312DWD 1234 (2.6Ah) Ni-MH 1pc. DC1411
     *DA312DWF 1235 (3.0Ah) Ni-MH 1pc. DC1411
                Remark : Models marked with * come with plastic carrying case.
 Specification
                       Model No.
     Specifications                       DA302D                   DA392D                  DA312D
    D/C Voltage (V)                         7.2                      9.6                     12
    No load speed : (min -1= rpm)                                  0 - 800
    Chuck ability                                                  0.8 - 10
             : mm ( " )                                            (1/32 - 3/8)
    Drilling            in Steel           10 (3/8)                           10 (3/8)
    capacity : mm ( " ) in Wood            10 (3/8)                           12 (1/2)
                        Screw                                Wood screw 4.5x20
                                                                       (3/16x3/4)
                        N.m             Approx. 4.0                          Approx. 5.0
    Max. fastening
                        Kgf.cm          Approx. 40.8                        Approx. 51.0
    torque
                        ft.lbs           Approx. 3.0                         Approx. 3.7
    Over current relay                                              Yes
    Electric brake                                                  Yes
    Reverse switch                                                   Yes
    Net weight :Kg (lbs )                   1.1 (2.4)              1.3 (2.9)                1.4 (3.1)

  Standard equipment
   * Battery cover .................... 1 pc. (except Model DA302D, DA392DZ, DA312DZ)
   * Plastic carrying case .......... 1 pc. (except Model DA302D, DA392DZ, DA312DZ)
   < Note > The standard equipment for the tool shown may differ from country to country.
Optional   accessories                                                                                       P2/6
 * Various drill bits for metal and wood working       For DA302D
 * Philips bit 1-65/2-45/2-65/2-110/2-150/2-250/       * Battery 7000 / 7002 / 7033
               3-45/3-65/3-110                         * Charger DC9710 / DC9711 / DC1201 / DC1411
 * Slotted bit 5-45/6-70/5-82/6.35-45/8-45/8-70                   DC1422 / DC1439 / DC1470 / DC1801
 * Buff 125                                            For DA392D
 * Wool bonnet 100                                     * Battery 9100 / 9102 / 9102A / 9120 / 9122 / 9133 / 9134 / 9135
 * Rubber pad assembly                                           9135A
                                                       * Charger DC9710 / DC9711 / DC1201 / DC1411
                                                                  DC1422 / DC1439 / DC1470 / DC1801
                                                       * Set plate for battery 9100 / 9102 / 9102A
           / 1200A / 1202 / 1202A                      For DA312D
                                                       * Battery 1200 / 1200A / 1202 / 1202A / 1220 / 1222 / 1233 /
                                                                  1234 / 1235 / 1235A
                                                       * Charger DC1201 / DC1411 / DC1422 / DC1439
Features    and benefits                                           / DC1470 / DC1801
                                                       * Set plate for battery 1200 /1200A / 1202 / 1202A
                                          DA302D
 Equipped with keyless drill chuck

                                                                                  Not only the existing battery 7000,
                                                                                  but also Ni-MH battery 7033 (2.2Ah)
                                                                                  can be used.


                                                                  Equipped with pod type battery with push button.
                                                                  Also batteries without push button can be used
                             DA392D
                                                                  with set plate which is an optional accessory.




                                                   DA312D




                                                                    More working amount with 12V battery
                                                                    compared with Model DA391D

Comparison      of products
             Model No.                    7.2V                                 9.6V                       12V
  Specifications               DA302D            DA301D            DA392D             DA391D             DA312D
 No load speed                 0 - 800           0 - 700            0 - 800            0 - 800         0 - 800
        : (min -1= rpm)
 Max. fastening torque       Approx. 4 N.m Approx. 4 N.m                 Approx. 5 N.m                Approx. 5 N.m
 Drilling            Steel               10 (3/8)                            10 (3/8)                  10 (3/8)
 capacity:mm (") Wood                    10 (3/8)                            12 (1/2)                  12 (1/2)
 Keyless drill chuck               Yes                No                        Yes                        Yes
 * Height of head :mm (")    104 (4-1/8 )       94 (3-11/16 )     104 (4-1/8 )     104 (4-1/8 )       104 (4-1/8 )
 Overall length :mm (")      296 (11-5/8 )    290 (11-3/8 )       324 (12-3/4 )     335 (13-1/4 )     324 (12-3/4 )
 Net weight :Kg (lbs )       1.1 (2.4 )           1.2 (2.7 )                  1.3 (2.9 )                1.4 (3.1 )



             * Height of head :mm (")
Comparison       of products                                                                                                        P3/6
  Numbers in chart below are relative values when setting the capacity of Mod.DA301D equipped with
  1.3Ah battery as 100.

                                                                                       Working amount
            Working speed                                                              with one full charged battery
                                          Employment as a screwdriver

 Fastening screws of
