Image preview - the first page of the document
DA3000R-TE


>> Download DA3000R-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.             DA3000R
                                                                                                                                                           New Tool


     Description            10 mm angle drill

CONCEPTION AND MAIN APPLICATIONS
   The model is similar to the model DA3000 and DA3000V except for
   for the newly employed reversible function and developed at the request
   from the export markets. The model displays its advantages in the
   wider uses, such as removing screws, and pulling wood working drills
   out of wood material.




                                                                                                                      Knob (to switch between the forward and reverse rotation.)

                                                                                                                                  [Outside drawing of DA3000R]

  Standard equipment
   Same as for DA3000 and DA3000V models.

  Optional accessories
   Same as for DA3000 and DA3000V models, except the following.
   It exhibits its advantages in removing screws and pulling wood working drills out of wood material with the variable
   speed reversible motor.

  Capacity
   Same as for DA3000 and DA3000V models.

  Repair
   Same as for DA3000 and DA3000V models, except for the motor.
                                                                     The pin moves up when the switch is turned on.




   (i) The reversible switch can not be operated unless the
       variable switch is turned off to protect the reversible
       switch as shown in the fig. on the right.
       Therefore you should never install the switch for                                                                 Switch(for reverse)
       DA3000V model by mistake, otherwise the reversible
       switch could be broken.                                                                                                                 Switch cover C




                                                                                                                                Switch
                                                                                                                                (different from the one for DA3000V model)

                                                                                                                       Motor housing cover



 The standard equipment for the tools shown may differ from country to country.
