Image preview - the first page of the document
DA4000LR-TE


>> Download DA4000LR-TE documenatation <<

Text preview - extract from the document
N     EW MODEL INFORMATION
    Models No.            DA4000LR
                                                                                                              PRODUCT
                                                                                                                P 1 / 11

    Description           13mm (1/2") Angle Drill

CONCEPTION AND MAIN APPLICATIONS                                                             L
   This model is the higher power version of the existing
   Model 6300LR.
   Its brief benefits and features are                                                                                 H1
     1. Easier upsetting angle attachment for change
        of working mode (high / low speed)                       H2
        thanks to the new formed drill chuck.                                                      W
     2. More durable gears in the angle attachment.
     3. Light weight and easy to operate.
     4. D - formed handle for easy gripping.                                         Dimensions : mm ( " )
                                                                                   Length (L)       413 (16-1/4)
                                                                                  Height (H1)            153 (6)
                                                                                  Height (H2)            144 (5-5/8)

  Specification                                                                   Width (W)               83 (3-1/4)

                                                                   Continuous Rating (W)
      Voltage (V)        Current (A)         Cycle (Hz)                                                Max. Output(W)
                                                                  Input           Output
          120               7.5               50 / 60             850              440                      600
          220               3.4               50 / 60             710              300                      600
          230               3.2               50 / 60             710              300                      600

    No load speed                 (High)     0 - 900 with angle attachment
                                                                                 0 - 600 without angle attachment
        : (min -1= rpm)           (Low)      0 - 400 with angle attachment
    Chuck ability : mm ( " )                                       2- 13 (1/16 - 1/2)
                        in Steel                                          13 (1/2)
    Drilling                     (High)     Auger bit : 38 (1-1/2) Selfeed bit : 65 (2-9/16)     Hole saw : 114 (4-1/2)
    capacity : mm ( " ) in Wood
                                 (Low)      Auger bit : 38 (1-1/2) Selfeed bit:118 (4-5/8)       Hole saw : 152 (6)
    Reverse switch                                                           Yes
    Variable switch                                                          Yes
    Protection from electric shock                                 by double insulation
    Cord length : m ( ft )                                               2.5 (8.2)
    Net weight :Kg (lbs )                                                3.7 (8.1)



 Standard equipment
    * Side grip for DA4000LR ............................... 1 pc.
    * Side grip for angle attachment ....................... 1 pc.
    * Chuck key ....................................................... 1 pc.
    * Hex wrench ..................................................... 1 pc.
    * Plastic carrying case ....................................... 1 pc.
   < Note > The standard equipment for the tool shown may differ from country to country.
 Optional     accessories
    * Angle attachment                                       * Side grip (for Angle attachment)
    * Extension attachment                                   * Drill chuck
    * Depth guide assembly                                   * Chuck key
    * Side grip (for DA4000LR)
Features   and benefits                                                                                     P 2 / 11

    Model DA4000LR
                                                                                  Palm fitting soft handle
    Increased durability of gear in
                                                  Switch is not only durable
    the angle attachment                          and high dust proof, but also
                                                  comfortable to operate with               Tough cord guard in
                                                  big trigger.                              ideal assembling
                                                                                            position
   Swivel side grip can                                                                     Excellent in flexibility to
   be attached on                                                                           protect the cord from
   angle attachment                                                                         disconnection.
                                                                                            And its ideal assembling
                                                                                            position as per the
                                                                                            illustration does not
                                                                                            interfere with the operator's
                                                                                            action.




                                             For speedy upsetting the angle attachment
                                             for changing (high / low speed), drill chuck
                                             can be removed faster than the existing one.


               After unscrewing this screw                   After removing this screw,
               you can only pull out                         remove the drill chuck by
               the drill chuck with your                     turning.
               hand.



  You can enjoy comfortable work
  due to lighter weight than the             DA4000LR                                The existing model
  competitors.


  Superiority to competitors in
  drilling performance as shown                              Come with so big plastic carrying case
  in the next page.                                          that you can put the machine into it without
                                                             detaching 4" hole saw or selfeed bit.




    Extension attachment can be used with
    Model DA4000LR.
    < Note > This accessory is an
             optional accessory.
Comparison       of products in drilling capacity                                                                   P 3 / 11
 Numbers in graph below are relative values when setting competitor A's capacity as 100.
 From the following graph you can understand
 1. Superiority to competitor A's product
 2. Tougher than competitor B' product especially in the drilling large hole, or in the drilling with heavy load.

  < Operation as an angle drill with high speed mode >
  The equipped bit : Auger bit
