Image preview - the first page of the document
DA4030-TE


>> Download DA4030-TE documenatation <<

Text preview - extract from the document
T ECHNICAL INFORMATION
     Models No.                  DA4030, DA4031
                                                                                                                                PRODUCT
                                                                                                                                   P 1 / 13


     Description                 Angle Drill 13mm (1/2")


CONCEPTION AND MAIN APPLICATIONS                                                                                     W

    These models are Makita's new 13mm (1/2") Angle Drills.
    And they are optimum for pro's close-quarter works in corners,
    between joists or studs.                                                 H
    * Model DA4030 is a single-speed drill; features superb drilling
      capacities, and targets electricians who drill more than
      300 holes a day.
                                                                                                       CH
    * Model DA4031 is a two-speed drill.                                                                        L
      While having the same benefits as DA4030,
      DA4031 features torque limiter in low speed,
                                                                                                  Dimensions: mm (")
      and targets plumbers; in low speed, powerful enough
      to smoothly drill large holes for pipe or conduit.          Model No.                          DA4030              DA4031
                                                                  Length (L)                          417 (16-3/8)       462 (18-1/4)
                                                                               Width (W)              102 (4)            102 (4)
                                                                               Height (H)             148 (5-7/8)        148 (5-7/8)
 Specifications                                                                Center height (CH)      40 (1-9/16)         40 (1-9/16)
                                                                                 Continuous Rating (W)
       Voltage (V)              Current (A)            Cycle (Hz)                                                   Max. Output(W)
                                                                                Input           Output
            110                      10.0                50 / 60               1,050              400                      1,200
            120                      10.0                50 / 60              (1,150)             400                      1,200
            230                       4.8                50 / 60               1,050              400                      1,200
            240                       4.6                50 / 60               1,050              400                      1,200


    Specifications                   Model             DA4030                                                DA4031
    Chuck capacity: mm (")                             2 - 13 (1/16 - 1/2)                                2 - 13 (1/16 - 1/2)
    No load speed: (min-1=rpm)                         1,200                                                 300/1,200
                              Auger bit               38 (1-1/2)                                             38 (1-1/2)
     Cutting     Wood                                                                       in high speed mode            118 (4-5/8)
     capacities:      Selfeed bit                      65 (2-9/16)
                                                                                            in low speed mode              65 (2-9/16)
     mm (")
                      Hole saw                                                               152 (6) only in low speed mode
                   Steel                               13 (1/2)                                               13 (1/2)
                                                                                            in high speed mode             80
    Max. torque: (N.m)                                     80
                                                                                            in low speed mode          145
    Torque limiter                                        No                                          Yes ( only in low speed)
    Reversing switch                                      Yes                                                   Yes
    Swivel-type rear handle                               Yes                                                   Yes
    Protection from electric shock                 Double insulation                                     Double insulation
    Cord length: m (ft.)                               2.5 (8.2)                                               2.5 (8.2)
    Net weight: Kg (lbs)                               4.8 (10.6)                                              5.6 (12.3)


 Standard equipment                                                                             Optional       accessories
    * Chuck key         .............1 pc.   * Key holder 13 .................. 1 pc.               * Drill chuck S13
    * Hex wrench................ 1 pc.       * Plastic carrying case ........ 1 pc.                 * Chuck key
    * Grip 27....................... 1 pc.                                                          * Grip 27
                                                                                                    * Hex wrench
                                                                                                    * Plastic carrying case
 Features      and benefits                                                                                         P 2 / 13
                                          Model DA4030, DA4031

    Superiority to competitors
    in drilling capacity
   Numbers in chart below are relative values
   when setting the capacity of Competitor's Mod. B as 100.


                                                                                            (Mod. DA4031 only)
     Material : 6 layered SPF,                    Material : A piece of SPF                Material : A piece of SPF
     Employed bit : Auger Bit 1-1/2"              Employed bit : Selfeed Bit 2-9/16"       Employed bit : Selfeed Bit 4-5/8"
DA4030,
                                           135                           120                                       105
DA4031
Competitor A
                                    100                               100                                        100
Mod. A
Competitor B                        100                                                                          100
                                                                      100
Mod. B
               0       50         100      150    0        50      100      150            0        50       100         150


                                                                  Palm-fitting soft grip
      Torque limiter (only Mod.DA4031)
       The shock can be suppressed, when
       the drill bit is locked.


    Front handle with space
    for storing hex wrench
    with which the front handle
                                                                                               Toolless swivel handle
    can be detached.
                                                                                               Handle can be swiveled
                                                                                               without any tool at 90
