Image preview - the first page of the document
DA6300-TE


>> Download DA6300-TE documenatation <<

Text preview - extract from the document
T       ECHNICAL INFORMATION

                                DA6300
                                                                                                                    New Tool

         For Models
         Description            13mm(1/2")Angle Drill                                                    410mm
                                                                                                        (16-1/8")


CONCEPTION AND MAIN APPLICATIONS




                                                                                   (6-11/16")
Two speed model squeezes in to drill in narrow corners.




                                                                                     170mm
Reversing feature to remove stuck kit and clean drill hole.
Low r.p.m makes it ideal to stir point, etc.
Triple reduction gearing.
                                                                                                  Width : 120mm (4-3/4")



   Specifications
                                                                           Continuous Rating(W)
        Voltage(V)          Current(A)            Cycle(Hz)                                                   Max. Output(W)
                                                                          Input            Output
            100                  8.5                 50/60                 810              380                      550
            115                  7.5                 50/60                 810              380                      550
            200                  4.3                 50/60                 810              380                      550
            220                  3.9                 50/60                 810              380                      550
            230                  3.8                 50/60                 810              380                      550
            240                  3.5                 50/60                 810              380                      550
     No Load Speed                                                   1,200R/min. (High)
                                                                     300R/min. (Low)
     Max.Drilling Capacities                                         Steel 13mm(1/2")
                                                                     Wood 36mm(1-3/8")
     Net Weight                                                      4.3kg (9.5lbs)


   Standard       equipment
    Chuck key S13, Key holder 12, Side grip 30, Steel carrying case


   Optional       accessories
    Hold saw assembly 79, 95


   Features       and benefies
    1. 2-speed for efficient drilling in both wood and metal.
    2. Forward/reverse switch for easy removal of the bit and easy clean-out of a hole.
    3. Can be used for mixing a variety of materials including paints, sprays, plaster, etc. with a mixing blade.
    4. Powerful Makita motor (810W) and triple reduction gearing for powerful operation.
    5. Removable 2-position side grip and swivel-type spade grip.
