DBM080
                                              DBM080 DBM080 Parts List

 Pos.             Item No.              Description                      Remarks
   1    P-26185              POWER SUPPRY CORD
   2
   3    EE    73320305       CONDENSER
   4    EE    73320260/1     HANDLE COVER CPL.
   5    EE    71323255       CORD GUARD
   6    EE    80600116       SWITCH
   7    EE    80201272       PAN HEAD SCREW 4,2x22
   8    EE    71540330       STRAIN RELIEF
   9    EE    80201270       PAN HEAD SCREW 4,2x13
  10    EE    80201267       PAN HEAD SCREW 4,8x45
  11    EE    73110620       GASKET
  12    210024-0             BALL BEARING 608 2RS
  13     EE 83000036         O-RING 22x2,5
  14     EE 80201196         BRUSH HOLDER CPL.
  15     EE 80700013         BRUSH
  16     EE 80201180         SCREW M4x12
  17     EE 80201385         WAVE WASHER
  18     EE 80900157         MOTOR HOUSING
  19     EE 80201265         PAN HEAD SCREW 3,9x70
  20     EE 73110140         BAFFLE PLATE
  21     EE 80201333         RETAINING RING 28
  22    211142-7             BALL BEARING 6001LLB
  23     EE 73110125         GASKET
  24     EE 73110430         HELICAL GEAR
  25     EE 80200504         WASHER 15
  26    211251-2             BALL BEARING 6003LLB
  27     EE 73113400         GEAR HOUSING COMPLETE
  28    211256-2             BALL BEARING 6203LLB
  29     EE 73113420         SPINDLE
  30
  31
  32
  33
  34
  35
  36
  37    EE 80200582          PIN 4
  38
  39
  40
  41
  42    EE 73116493          COUPLING
  43
  44    EE    73113610       BEARING RETAINER
  45    EE    73116100       ARMATURE ASS'Y
  46    EE    73116150       FIELD ASS`Y
  47    EE    73116280       CONTROLLER
  48    EE    80201252       PAN HEAD SCREW 2,9x13
  49    EE    83000053       PLUG
  50
  51    EE 85000061          WASHER 5
  52    EE 83000035          O-RING 4,9x1,9
  53    EE 73116695          HANDLE CPL.
