Image preview - the first page of the document
DC1412-TE


>> Download DC1412-TE documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION                                                                          New Tool

         For Models           DC1412
          Description         Fast Automotive Charger




                                                                                                       92 5/8"
                                                                                                        (3-
                                                                                                          mm )
CONCEPTION AND MAIN APPLICATIONS




                                                                    78mm ")
                                                                   (3-5/64
This fast automotive charger,which power source is
the inlet of the cigarette lighter in the car,
can accept DC 7.2V,9.6V,12V and14.4V Ni-Cd batteries.                                   193mm ")
                                                                                              32
                                                                                       (7-19/

   Specifications
          Voltage(V)                 Input
             12-24V                   50W


   Capacity
     Output voltage : DC7.2V,9.6V,12V,14.4V
     Output current : DC1.8A
     Charging time : 45min.for 1.3Ah battery(Battery 7000,7100,9000,9100,9100A,9120,1200,1200A,1210)
     60min.for 1.7Ah battery(Battery 7001,9001,9101,9101A,1201,1201A,1211)
      70min.for 2.0Ah battery(Battery 7002,9002,9102,9102A,9122,1202,1202A,12020A,1422)
     Net weight : 0.53Kg(1.17lbs)
     Cord length : 2.0m(6.6ft)
Repair
The delivery of charging circuit of DC1410/LG123 for repair has been stopped
because of starting production of DC1411/LG124 and the charging circuit of
DC1411/LG124 is to be used for replacement. Note that you should remove one
charging terminal as shown in the figure below when replacing a charging circuit of
DC1410/lG123.




          Can be used for
                                                    Automatic charging of heated battery after use
          both 12V and 24V power source
                                                    You may leave heated battery,
           Charging time is the same                after coolen-down,it automatically starts charging.
           with 12V and 24V power source.            (the same as DC1410)




                                                       Charging condition is displayed
                                                       by green or red light.
          High capacity battery                                   (the same as DC1410)
          can be charged.
           1. 3Ah battery(nomal capacity)
            Charging time : 45min.
           1. 7Ah battery(high capacity)
            Charging time : 60min.
           2. 0Ah battery(high capacity)
            Charging time : 70min.
