Image preview - the first page of the document
DC24SA-TE


>> Download DC24SA-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION
    Models No.            DC24SA
                                                                                                             PRODUCT
                                                                                                               P1/8

     Description           Charger
CONCEPTION AND MAIN APPLICATIONS
    This new charger allows you to charge new Ni-MH battery                    H
    from 7.2V to 24V. This charger contains trickle charging function.
    Its brief benefits are listed below.
    1. The charging time for new 24V Ni-MH batteries is as follows.
        * B2417 / 1.7Ah : approx. 30 min.                                        W
                                                                                                       L
        * B2430 / 3.0Ah ; approx. 60 min.
    2. Innovative computer controlled charging system realized most suitable
       charge by making the digital communication between charger and battery.
    3. Cooling system to keep the ideal temperature for charge.
                                                                                        Dimensions : mm ( " )
    4. Power display for battery ; It displays the charging amounts of battery
       in two steps. (less than 80% or more than 80% of charge)                    Width ( W ) 175 (6-29/32)
    5. The adapter ADP01 (optional acc.) enables to charge the existing            Height ( H ) 110 (4-5/16)
       7.2V - 24V Ni-Cd and Ni-MH batteries, too.                                  Length ( L ) 215 (8-15/32)
    6. The adapter ADP02 (optional acc.) enables to refresh inactive
       batteries



 Specification
                         Output                                             Continuous Rating (W)
      Voltage (V)                               Cycle (Hz)                                          Output Voltage (V)
                         Current (A)                                       Input           Output
              120          D/C 6.5               50 - 60                    135                       D/C 7.2 - 12
        220 - 240          D/C 6.5               50 - 60                    135                       D/C 7.2 - 12
        230 - 240           D/C 6.5              50 - 60                    135                        D/C 7.2 - 12

    Charging time
                                                                      The existing battery
                                        New battery                   (adaptor is required)
     Voltage ( V )                   7.2 - 18         19.2 - 24              7.2 - 18
                                      35                 60                    40
               Ni-MH 3.0 Ah
                          2.6 Ah                                               35
     Charging             2.2 Ah                                               30
     time                            20                  30
                          1.7 Ah
               Ni-Cd 2.0 Ah                                                    20
                          1.7 Ah                                               17
                          1.3 Ah                                               13
     Power display for battery                  Yes                            No
     Cooling fan                                Yes                            No
     Cord length : m (ft)                                 2.0 (6.6)
     Net weight :Kg (lbs )                                1.7 (3.7)


  Optional     accessories
  * Interchangeable adapter ADP01 for the existing batteries
  * Refreshing adapter ADP02
Features   and benefits                                                                                         P 2/8
                                        Chargeable for 7.2V - 24V
                                        batteries




                                                                                   Charging light indicating charging
                                                                                   process and charging condition
                                                                                   with red, green and yellow
  Longer life of battery
  The following innovative systems extend the battery's life approx.50% longer.
  1. Conditioning charge
    The charger receives distinctive data (temperature, history of usage ect.)
    from built-in memory chip installed in battery, and decides the most suitable conditions to charge the battery.
    The conditioning charge will start, when the battery is employed repeatedly under the following conditions,
    which have bad influence on battery's life.
      1. Charge under high room temperature (higher than 40
