Image preview - the first page of the document
HK1800-TE


>> Download HK1800-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
      Models No.               HK1800
                                                                                                     New Tool


      Description              Makita Power scraper

CONCEPT AND MAIN APPLICATIONS                                                               315
   This model was developed as the small special tool to




                                                                            85
   remove concrete adhered to floors and concrete molds
   (whitewash removal), to separate plastic tiles, cushion floors,
   exterior tiles at construction sites, to separate foreign matters




                                                                                                          192
   adhered on the ship hulls, and for the light scaling jobs.
   As the bit tip angle can be indexed by every 60 degrees on the
   model to suit works to be carried out.




  Specifications
      Voltage(V)          Current(A)       Frequency(Hz)             Continuous rating          Max.
                                                                  Input(W)      Output(W)     output(W)
          100                 5.2                50-60               505             180         400
          115                 4.5                50-60               505             180         400
          200                 2.6                50-60               505             180         400
          220                 2.4                50-60               505             180         400
          240                 2.2                50-60               505             180         400

    Blows per minute(/min.)                      3200/min.
    Weight(kg)                                   3.2kg
    Power supply cord(m)                         5m




  Standard equipment
   Scaling chisel 30 x 150mm
   Scaling chisel 50 x 150 mm
   Bull point 13 in diameter x 220 mm
   Hex. spanner


  Optional accessories
   Bull point 13 x 220 mm
   Scaling chisel 30 x 150 mm
   Scaling chisel 50 x 150 mm
   Lock nut wrench 28
   Hammer grease (30 g)
   Eye protecting glasses




 The standard equipment for the tools shown may differ from country to country.
Features and benefits
1.     Its air cushion system provides you with the strong impacting force by lightly holding the unit down, making
       the unit most suitable for scaling jobs.
2.     Its one action tool retainer makes the replacement of bits easy.
3.     The bit can be set at the desired angle in every 60
