Image preview - the first page of the document
HM1500B-TE


>> Download HM1500B-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.              HM1500B
                                                                                                         Product


     Description             Demolition Hammer

CONCEPTION AND MAIN APPLICATIONS                                             807 mm(31-3/4")

  Model HM1500 is basically the same as the
  existing models HM1500 except the bit
  retaining portion.
  HM1500B accepts 28.6mm(1-1/8")
  hex shank bits for Pneumatic Breaker.
                                                                                                               232 mm(9-1/8")


                                                                                  118 mm(4-5/8")

  Specifications
                                                                  Consumed             Rated       Max. output(W)
       Voltage(V)        Current(A)         Cycle (Hz)
                                                                  power(W)            output(W)
          100                 15.5             50/60                1470                 820            1540
          115                 13.5             50/60                1470                 820            1540
          200                  7.7             50/60                1470                 820            1540
          220                  7.0             50/60                1470                 820            1540
          230                  6.7             50/60                1470                 820            1540
          240                  6.4             50/60                1470                 820            1540



           Blows per Minite                              1300

                Net weight                             19.0kg(41.9lbs)



 Standard equipment
   Hex Wrenches 5,6,10
   Steel Carring Case


 Optional accessories
   Hammer Grease




 Features and benefits
  1. Accepts 28.6mm(1-1/8") hex shank bits for Pneumatic Breaker.
  2.Demolotion capacity is about 30% higher than that of existing Model HM1300.
  3.Shock absorbing handles reduce operator fatigue.
  4. Side handle swings 360
  Antivibration handles to reduce operator fatigue.
  5. Cushion ring(rubber) between motor housing and brush holder lessens
    vibration of brush holder and prevents brakage of ring terminal.
  6. Greese packed
  7.Automatic cut off brushes
  8.Double insulated for operator safety


 The standard equipment for the tools shown may differ form country to country.
