Image preview - the first page of the document
HM1100-TE


>> Download HM1100-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
      Models No.            HM1100
                                                                                                          New Tool


      Description           Demolition Hammers

CONCEPTION AND MAIN APPLICATIONS                                                         98m
                                                                                            m(3-
                                                                                                7/8"
                                                                                                      )
   Model HM1100C is the hammer classed between Model
   HM0810 and Model HM1200, and it's brief benefits are;




                                                                                                                224mm(8-7/8")
   *Less vibration toward hands than competitor's same class
     hammers by improved over all design
   *Reduced operator' s fatigue in cotinuous operation by
    ergonomically designed large handle, well balanced side
     handle and slide switch
   *Easy operation for light hammering by electronical speed
    adjusting dial at lower blows per minute position                                524mm(20-5/8")
   *Adapted for SDS-max type bit Model HM1l00 is the model
     without electronical) speed control feature.


   Specifications
                                                                 Continuous Rating (W)
      Voltage (V)       Current (A)        Cycle (Hz)                                      Max. Output(W)
                                                                Input          Output
          100               11               50/60              1050             450               1050
          115               9.6              50/60              1050             450               1050
          200               5.5              50/60              1050             450               1050
          220                5               50/60              1050             450               1050
          230               4.8              50/60              1050             450               1050
          240               4.6              50/60              1050             450               1050

    Bit-type                                   SDS-max
    Blows per minute          HM1100C          1300-2650(bpm)
                              HM1100           2650(bpm)
    Net Weight                                 6.1Kg(13.5lbs)
    Cold Length                                5m(16.4ft)


   Standard equipment
    Bit Grease Plastic Carrying Case


   Optional accessories
    Hammer Grease


   Features and benefits
    1.Double insulated
    2.See the attached sheets for more information.




The standard equipment for the tools shown may differ form country to country
   Better feeling in use than Model TE704(HILTI) and Model GSH5CE(Bosch)
     . Same efficiency as Model TE704(HILTI) and better than Model GSH5CE(Bosch).
        More ergonomic than Model TE704(HILTI) and Model GSH5CE(Bosch).
      . No different feeling will be felt at your hands after long continuous use(approx.30minutes)




Chisel or Spade can be
set at 16 different angles.
Bit'angle can be changed with bit in tool holder
by pushing change ring and turning it.




                                                                                                                On-off slide switch
                                  360
                                                                                                                 suitable for
                                                                                                                 continuous use



                                                                                                                   Large handle
                                                                                                                     . Ergonomic shape
                                                                                                                     . Switch is removed.
                                                                                                                     . Large enough
                                                                                                                        for both hands
                                                                                                                        at stright-down work
                                                                                                                      . Roundish shape for
                                                                                                                        supporting tool by
                                                                                                                        other part of the body
                                                                                                                        without pain




                                                                 D-Side handle
No hammering when idling                                          Can be set at any angle                         Speed adjusting dial
Bit does not jump arround.                                        and swiveled at 8 positions                     (HM1100C only)
Efficiency and endurance                                          back and forth                                   Light hammering is easily
are improved.                                                    Ergonomic body shape                             performed by setting at
                                                                  Body can be held                                low blows per minute.
                                                                  without side handle.




                                    Bit can be installed or removed
                                    by sliding tool holder cover.
                                                                                                      Steady speed + Soft start
                                                                                                      (HM1100C only)
                                                                                                      Easy to locate bit by
                                                                                                      electronical speed control
