HM1200B-TE


>> Download HM1200B-TE documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION

                               HM1200B
                                                                                                                  New Tool

          For Models
          Description          Demolition Hammer


CONCEPTION AND MAIN APPLICATIONS                                                               490mm (19-5/16")

Model HM1200B, is basically the same as the existing Model
HM1200 expect the followings.
  *Model HM1200B accepts chisels for Bosch USH 10.




                                                                                                                          250mm (10")
  *Model HM1200B has a convenient D-shaped handle
  (auxiliary handle).
Model HM1200B is an excellent tool for cutaway, digging,
                                                                            144mm (5-11/16")
asaling applications.


    Specifications
                                                                           Continuous Rating(W)
        Voltage(V)          Current(A)           Cycle(Hz)                                                   Max. Output(W)
                                                                          Input            Output
            100                 12.0               50/60                  1,130             600                   800
            115                  8.7               50/60                   940              540                   800
            200                  5.0               50/60                   940              540                   800
            220                  4.5               50/60                   940              540                   800
            230                  4.3               50/60                   940              540                   800
            240                  4.1               50/60                   940              540                   800
      Blows per Mimute                                            2,000
      Net Weight                                                  9.4kg (20.7lbs)


    Standard      equipment
     Hex Wrench 4, Hex Wrench 8, Steel Carrying Case


    Features      and benefits
     1. Accepts chisels for Bosch USH 10
     2. Convenient D-shaped handle (auxiliary handle) for easy handling
     3. Double insulation for operator safety
     4. Antivibration spring reduces fatigue
     5. Cooling air flow away from operator
     6. Grease-packed for 150 hours
     7. Excellent tool for cutaway, digging, scaling applications
     8. Handy steel carruing case
