Image preview - the first page of the document
HM1242C-TE


>> Download HM1242C-TE documenatation <<

Text preview - extract from the document
  T     ECHNICAL INFORMATION
      Models No.           HM1242C
                                                                                     112mm(4-3/8")
                                                                                                              PRODUCT
                                                                                                                   P 1/ 14

       Description         Demolition Hammer




                                                                                                                    258m
CONCEPTION AND MAIN APPLICATIONS




                                                                                                                     m(10
      HM1242C is the 10 Kg class hammer for BOSCH shank type




                                                                                                                       -1/8"
      hammer bits (3/4" Hex 21/32 Round shank)
      This model is taking over the existing HM1202C's benefits




                                                                                                                            )
      in incredibly low noise, compact body and the strongest
      demolishing power in this class.

                                                                                                       )
                                                                                              22- 1/2"
                                                                                       572mm(




    Specification
                                                                    Continuous Rating (W)
         Voltage (V)       Current (A)        Cycle (Hz)                                            Max. Output(W)
                                                                   Input           Output
            100                 15              50 / 60            1,450             500                   1,600
            115                 15              50 / 60            1,450             500                   1,600
            120                 13              50 / 60            1,450             500                   1,600
            220                  7.3            50 / 60            1,450             550                   1,800
            230                  7.0            50 / 60            1,450             550                   1,800
            240                  6.7            50 / 60            1,450             550                   1,800

                                                  BOSCH shank type
       Bit-type                                   hammer bits
       Blows per minute                            950-1,900 (bpm)
       Net Weight                                  9.3kg (20.5 lbs)
       Size of shank                               (3/4" Hex 21/32 Round shank)
       Cord Length                                  5m (16.4 ft)

    Standard equipment
      Grease for bit ........... 1 pc.
      < Note > The standard equipment for the tool shown may be differ from country to country.

    Optional  accessories
      Bull point 19-300                                    Grooving chisel 22-300
      Bull point 19-450                                    Grooving chisel 26-300
      Cold chisel 26-300                                   Clay spade 105-400
      Cold chisel 26-450                                   Rammer 140
      Scaling chisel 50-300                                Bushing tool 67-300
HM1242C
                                                                                              P 2 / 14
 Full resin covered body
 to protect the operator
 from the electric shock                                       Easy to hold the machine
                                                               due to light weight
                                                               Makita Mod.HM1202C : 9.3 Kg [20.5 lbs]
                                  Cylindric Barrel for         Competitor A Mod. A : 10.5 Kg [23.2 lbs]
                                  comfortable gripping         Competitor B Mod. B : 9.9 Kg [21.8 lbs]
                                                               Competitor C Mod. C : 9.7 Kg [21.4 lbs]
          Highly rigid aluminum
          side handle                            (2)                         (1)


   (5)




                                                                                   (8)

                                                                               Big and durable
                                                                               cord guard
         (6)      (7)                                                          protecting the cord
                                                         (3)                   from the fatigue by
         Chiseling performance being superior to (4)                           frequent inflection
         Competitor A, Mod.A by 20 %.
         Competitor B Mod.B by 10 %.
         Competitor C Mod.C by 50%.
         You can learn the above superiority easily             (9)
         by your trial operation.

Other features
1.Easy and comfortable long time operation thanks to ON-OFF slide switch which is not required
  to be pressed by operator during the work.
2.D-form side grip swivels 360
