Image preview - the first page of the document
HM1303-TE


>> Download HM1303-TE documenatation <<

Text preview - extract from the document
TECHNICAL INFORMATION                                                                          Product




                                                                                                   216 mm (8-9/16")
        Models No.              HM1303
        Description         Demolition Hammer
                                                                                116 mm (4-9/16")
CONCEPTION AND MAIN APPLICATIONS
Model HM1303 is a double-insulated version of model HM1302;
* Designed mainly for European and USA markets
* With grease-pack lubrication
* Much lighter body, lower vibration and less shock than existing
  model HM1500 for easier and more comfortable
                                                                                           )
  operation, especially in angular or horizontal work.
                                                                                m (29-1/2"
                                                                          747 m


   Specifications
                                                       Continuous Rating (W)
      Voltage (V)     Current (A)     Cycle (Hz)                                  Max. Output(W)
                                                       Input           Output
         100             13.5            50/60         1,300            750            1,000
         115             11.5            50/60         1,300            750            1,000
         200              6.8            50/60         1,300            750            1,000
         220              6.1            50/60         1,300            750            1,000
         230              5.9            50/60         1,300            750            1,000
         240              5.6            50/60         1,300            750            1,000

   Blows per minute/1.450
   Tool acceptable /Hexagonal shank bits-----Shank width: 30 mm (1-3/16 inch)
   Net weight    /14kg (30.9 lbs)



  Standard equipment
     Bull point 30 - 410, Steel carrying case


   Optional accessories
    Bull point, Cold chisel, Scaling chisel, Clay spade, Rammer, etc.
    (These accessories can be used interchangeably with HM1302 and HM1500.)


   Features and benefits
     See the attached sheet for more information.
     Note: The standard equipment shown above may differ from country to country.
   Light-weighted body and minimized shock assure you of less fatigue and increased demolishing capacity even
   in a long continuous operation, especially in angular or horizontal work.



    *Light body
      2.9kg(6.4 lbs) lighter than Makita HM1500



    *Demolishing capacity comparison (in weight of shifted concrete)
        In horizontal, 10 minutes continuous operation
         Makita HM1303 / 23.3 kg (51.4 lbs)
         Makita HM1302 / 20.5 kg (45.2 lbs)

       In vertical, 30 minutes continuous operation
        Makita HM1303 / 71.4 kg (157.4 lbs)
        Makita HM1302 / 72.6 kg (160.01 lbs)




                                                                             Rubber-clad handle for low
                                                                             Vibration and easy gripping
                            Grease pack lubrication system




Rubber dust cover to prevent         Effective air cushion prevents       Side grip rotates through360
