Image preview - the first page of the document
HM1303B-TE


>> Download HM1303B-TE documenatation <<

Text preview - extract from the document
T        ECHNICAL INFORMATION

                                  HM1303B
                                                                                                               New Tool

          For Models




                                                                                                                   (8-1/2")
                                                                                                                   216mm
                                                                                                116mm
           Description            Demolition Hammer                                            (4-9/16")




CONCEPTION AND MAIN APPLICATIONS
Model HM1303B is a sister model of model HM1303 ;
 *Designed to accept pneumatic hammer bits
 *With grease-pack lubrication
 *Much lighter body, lower vibration and less shock                                               m
                                                                                           823m 5")
  than existing model HM1500B or Cewpetitons one                                           (3 2-2/
  for easier and more confortable operation, especially
  in angular or horizontal work.


    Specifications
          Voltage (V)         Current (A)           Cycle (Hz)          Continuous Rating (W)              Max. Output (W)
                                                                        Input           Output
              100                  13.5                   50-60         1,300             750                   1,000
              115                  11.5                   50-60         1,300             750                   1,000
              200                   6.8                   50-60         1,300             750                   1,000
              220                   6.1                   50-60         1,300             750                   1,000
              230                   5.9                   50-60         1,300             750                   1,000
              240                   5.6                   50-60         1,300             750                   1,000


     Blows per minute/1,450
     Tool acceptable /Pneumatic hammer bits ......Hex. shank width : 28.6mm (1-1/8 inch)
     Net weight /16kg (35.3lbs)


    Standard        equipment
     Steel carrying case


    Optional        accessories
     Hammer grease


    Features      and benefits
     See the attached sheet for more information.


     (NOTE) The standard equipment shown above may differ from country to country.
Light-weighted body and minimized shock assure you of less fatigue and increased demolishing capacity even in a long
continuous operation, especially in angular or horizontal work.




                                                                                        Rubber-clad handle for low
                                                                                        vibration and easy gripping


                               Grease pack lubrication system




                               Effective air cushion prevents
                               the machine from losing blow to                          Side grip rotates through 360
