Image preview - the first page of the document
HM1304B-TE


>> Download HM1304B-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
   Models No.                  HM1304B
                                                                                                           PRODUCT
                                                                                                             P 1 / 13

   Description                 Demolition Hammer
CONCEPTION AND MAIN APPLICATIONS
   HM1304B is the sister model of HM1304, and hex 28.6mm                                      L
   (1-1/8") bit can be used with HM1304B.
   And this new product conforms to requirements of
   the new European noise regulation which will be effective                                                            H
   from 2006.



                                                                                                                    w
                                                                           Dimensions : mm ( " )
                                                                      Length ( L ) 831 (32-3/4)
                                                                      Width ( W )    115 (4-1/2)
 Specification                                                        Height ( H )   219 (8-5/8)

                                                                     Continuous Rating (W)
     Voltage (V)            Current (A)              Cycle (Hz)                                    Max. Output(W)
                                                                    Input           Output
         110                     14.0                 50 / 60        1,500           900                1,600
         120                     13.0                 50 / 60                        900                1,600
         220                      7.2                 50 / 60        1,500           900                1,600
         230                      6.9                 50 / 60        1,500           900                1,600
         240                      6.6                 50 / 60        1,500           900                1,600


   Blows per min, :(bpm=min -1)                   1,450
   Shank : mm (")                            28.6 (1-1/8) hex
   Single blow energy : J                          27.5
   Protection from electric shock            by double insulation
   Cord length : m ( ft )                       5.0 (16.4)
   Net weight :Kg (lbs )                        17.0 (37.5)




 Standard equipment
    * Steel carrying case ............................ 1 pc.


   < Note > The standard equipment for the tool shown may differ from country to country.

 Optional      accessories
    * Bull point             * Scaling chisel            * Rammer
    * Cold chisel            * Clay spade
Features             and benefits                                                                                           P 2 / 13

                                                                                             Rugged Side Handle
                               Low Noise Level                                         Swivels 360
