Image preview - the first page of the document
>> Download HP1620-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. HP1620, HP1620F, HP1621, HP1621F
PRODUCT
P 1 / 14
L L
Description Hammer Drills 16mm (5/8")
CONCEPT AND MAIN APPLICATIONS
The above products are up-grade version of the existing
models HP1500 and HP1501. H H
W W
Their features are as follows.
Model No. HP1620 HP1620F HP1621 HP1621F
F/R Change by
brush holder unit
LED Job Light HP1620 HP1621
HP1620F HP1621F
Keyless drill chuck
Dimensions : mm ( " )
Model No. HP1620(F) HP1621(F)
Length ( L ) 303 (11-7/8)
Height ( H ) 222 (8-3/4)
Specification Width ( W ) 68 (2-11/16)
Continuous Rating (W)
Voltage (V) Current (A) Cycle (Hz) Max. Output(W)
Input Output
110 6.2 50 / 60 650 380 500
110 for Taiwan 5.4 50 / 60 560 320 500
120 5.7 50 / 60 650 380 500
220 3.1 50 / 60 650 380 600
230 3.0 50 / 60 650 380 600
240 2.9 50 / 60 650 380 600
Model No. HP1620 HP1620F HP1621 HP1621F
No load speed : (min -1= rpm) 0 - 2,800
Blows per min. : (min -1= bpm) 0 - 44,800
Keyless chuck No No Yes Yes
Chuck ability : mm ( " ) 1.5 - 13 (1/16 - 1/2)
Concrete 16 (5/8)
Drilling
capacity : mm ( " ) Steel 13 (1/2)
Wood 30 (1-3/16)
F/R Change system Brush holder unit
LED Job Light No Yes No Yes
Protection from electric shock Double insulation
Cord length : m ( ft ) 2.0 (6.6)
Net weight :Kg (lbs ) 1.7 (3.8)
Standard equipment
* Side handle ....................................... 1 pc.
* Depth gauge ...................................... 1pc.
* Chuck key S-13................................. 1 pc. (only for HP1620 and HP1620F)
* Plastic carrying case ......................... 1 pc.
< Note > The standard equipment for the tool shown may differ from country to country.
Optional accessories
* T.C.T. Hammer drill bit ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
