Image preview - the first page of the document
HP1620F-TE


>> Download HP1620F-TE documenatation <<

Text preview - extract from the document
T     ECHNICAL INFORMATION
    Models No.                      HP1620, HP1620F, HP1621, HP1621F
                                                                                                                       PRODUCT
                                                                                                                         P 1 / 14

                                                                                                 L                        L
    Description                     Hammer Drills 16mm (5/8")

CONCEPT AND MAIN APPLICATIONS
   The above products are up-grade version of the existing
   models HP1500 and HP1501.                                                                               H                    H
                                                                                             W                     W
   Their features are as follows.
    Model No.           HP1620                  HP1620F         HP1621    HP1621F
    F/R Change by
    brush holder unit
    LED Job Light                                                                            HP1620                HP1621
                                                                                             HP1620F               HP1621F
    Keyless drill chuck
                                                                                       Dimensions : mm ( " )
                                                                                  Model No. HP1620(F)         HP1621(F)
                                                                                  Length ( L )       303 (11-7/8)
                                                                                  Height ( H )       222 (8-3/4)
 Specification                                                                    Width ( W )         68 (2-11/16)

                                                                                 Continuous Rating (W)
       Voltage (V)               Current (A)                Cycle (Hz)                                         Max. Output(W)
                                                                                Input           Output
          110                        6.2                     50 / 60             650              380               500
      110 for Taiwan                 5.4                     50 / 60             560              320               500
          120                        5.7                     50 / 60             650              380               500
          220                        3.1                     50 / 60             650              380               600
          230                        3.0                     50 / 60             650              380               600
          240                        2.9                     50 / 60             650              380               600
    Model No.                                      HP1620           HP1620F         HP1621       HP1621F
    No load speed : (min -1= rpm)                                           0 - 2,800
    Blows per min. : (min -1= bpm)                                          0 - 44,800
    Keyless chuck                                     No              No              Yes            Yes
    Chuck ability : mm ( " )                                         1.5 - 13 (1/16 - 1/2)
                         Concrete                                          16 (5/8)
    Drilling
    capacity : mm ( " ) Steel                                              13 (1/2)
                         Wood                                              30 (1-3/16)
    F/R Change system                                                  Brush holder unit
    LED Job Light                                     No              Yes             No             Yes
    Protection from electric shock                                     Double insulation
    Cord length : m ( ft )                                                  2.0 (6.6)
    Net weight :Kg (lbs )                                                   1.7 (3.8)

 Standard equipment
   * Side handle .......................................   1 pc.
   * Depth gauge ......................................    1pc.
   * Chuck key S-13.................................       1 pc. (only for HP1620 and HP1620F)
   * Plastic carrying case .........................       1 pc.
   < Note > The standard equipment for the tool shown may differ from country to country.

 Optional        accessories
   * T.C.T. Hammer drill bit
