Image preview - the first page of the document
HP2030-TE


>> Download HP2030-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.              HP2030
                                                                                                               New Tool


        Description             20 mm(3/4") 2-Speed Hammer Drill                          372mm (15-5/8")

CONCEPTION AND MAIN APPLICATIONS
 Model HP2030 is variable 2-speed professional hammer
 drill with reversing feature and powerful, fast masonry




                                                                                                                          195 mm(7-5/8")
 drilling capacity. It has i mpact-resistant handle with built-in
 rubber cushion.




                                                           31 mm(1-1/4")


                                                                                       Width 75mm (2-15/16")

  Specifications
                                                                     Continuous Rating (W)
       Voltage (V)        Current (A)         Cycle (Hz)                                         Max. Output(W)
                                                                    Input          Output
           100                7.5                50/60              710              330              620
           115                6.5                50/60              710              330              620
           200                3.8                50/60              710              330              620
           220                3.4                50/60              710              330              620
           230                3.2                50/60              710              330              620
           240                3.1                50/60              710              330              620

     Max. capacities        Concrete       Hi: 13mm (1/2")           Lo: 20mm (3/4")
                            Steel          Hi: 8mm (5/16")           Lo: 13mm (1/2")
                            Wood           Hi: 25mm (1")             Lo: 40mm(1-9/16")
     No load speed                         Hi: 0 - 2,900             Lo: 0 - 850
     Blows per minute                      Hi: 0 - 32,000            Lo: 0 - 9,400
     Net Weight                            2.4kg (5.3 lbs)
     Power supply cord                     2.5m (8.2ft)




  Standard equipment
      Drill chuck S13, Chuck key S13, Key holder 12, Depth rod, Plastic carrying case


  Optional accessories
      Various sizes of tungsten-carbide tipped bit, Hole saw 79, 95, Blow-out bulb


  Features       and benefits
      1.Double insulated
      2.For further information, see information sheet which we will send you later.




   The standard equipment for the tools shown may differ form country to country
This is additional information on Model HP2030 (2-3Speed Hammer Drill).
Attach this information sheet to MAKIT NEW TOOL INTRODUCTION NT-30/94.




                 Protrusions to prevent
                 side grip from coming loose

                                            Switch lever:
                                            Drilling         Hammer Drilling
                                                                                        Impact-resistant handle with
                                                                                        built-in rubber cushion



31mm(1-1/4")
                                                                                               Comfort-contoured handle
                                                                                               fits your palm; trigger
                                                                                               within easy reach


13mm(1/2") drill chuck

           Protrusions to prevent
           side grip from slipping
                                                                                                       Large, easy-to-use
                                                                                                       switch lock button




  Side grip swings 360 , secures
  at any angle; won't slip under pressure                    Comfortable, easy-to-use
                                                             variable speed switch




                                      Speed change lever to
                                      preselect one of two rpm ranges
