Image preview - the first page of the document
HP2031-TE


>> Download HP2031-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.            HP2031
                                                                                                              New Tool


     Description           20mm (3/4") 2-Speed Hammer Drill

CONCEPTION AND MAIN APPLICATIONS                                                      388mm(15-5/16")
  Model HP2031 is identical with the existing Model
  HP2030 except that Model HP2031 has a keyless chuck.




                                                                                                                    195mm(7-5/8")
                                                                31mm(1-1/4")




                                                                                           width:75mm(2-15/16")


  Specifications
                                                                 Continuous Rating (W)           Max. Output(W)
     Voltage (V)       Current (A)        Cycle (Hz)
                                                                Input          Output
        100               7.5               50/60               710              330                    620
        115               6.5               50/60               710              330                    620
        200               3.8               50/60               710              330                    620
        220               3.4               50/60               710              330                    620
        230               3.2               50/60               710              330                    620
        240               3.1               50/60               710              330                    620

   Max. capacities      Concrete              Hi: 13mm (1/2")                       Lo: 20mm (3/4")
                        Steel                 Hi: 8mm (5/16")                       Lo: 13mm (1/2")
                        Wood                  Hi: 25mm (1")                         Lo: 40mm(1-9/16")
   No load speed                              Hi: 0 - 2,900                         Lo: 0 - 850
   Blows per minute                           Hi: 0 - 32,000                        Lo: 0 - 9,400
   Net Weight                                 2.5kg (5.5 lbs)


  Standard equipment
   Keyless chuck, Depth rod, Plastic carrying case


  Optional accessories
   Various sizes of tungsten-carbide tipped bit, Hole saw 79, 95, Blow-out bulb

  Features and benefits
   1.Double insulated
   2. For further information, see information sheet which we will send you later




 The standard equipment for the tools shown may differ form country to country
