Image preview - the first page of the document
HP2033-TE


>> Download HP2033-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.               HP2033
                                                                                                         New Tool


        Description              20mm 2-speed motor drill

CONCEPTION AND MAIN APPLICATIONS                                               HP2032 370m
                                                                                           m (14-1/2")
                                                                                           m (14-1/2")
Model HP2032/HP2033 are sister versions of the existing model                  HP2033 368m




                                                                                                            195mm (7-5/8")
HP2030/HP2031.
And they are designed for more professional use than
HP2030/HP2031. Their brief benefit is:                              31mm
                                                                   (1-1/4")
*More strong housing than HP2030/HP2031 by aluminum Gear
 housing and Cam housing.
 HP2032 ------- With key drill chuck
 HP2033 ------- Keyless drill chuck

                                                                               Width 75mm (2-15/16")
    Specifications
                                                                Continuous Rating (W)             Max.
      Voltage (V)     Current (A)         Cycle (Hz)                                            Output(W)
                                                                Input           Output
          100              7.6              50/60                720             330               620
          115              6.6              50/60                720             330               620
          200              3.8              50/60                720             330               620
          220              3.4              50/60                720             330               620
          230              3.3              50/60                720             330               620
          240              3.2              50/60                720             330               620

     No load speed    Rotations        Low speed         0-850 rpm
                      per minute       High speed        0-2900 rpm
                      Blows            Low speed         0-9400 rpm
                      per minute       High speed        0-3200 rpm
     Drill chuck capacity                                1.5-13mm
     Max. drilling capacities          Concrete          L:N/A H:20mm
     (L/H)                             Steel             L:13mm H:8mm
                                       Wood              L:40mm H:25mm
     Net weight                                          2.5kg
     Cord length                                         2.5m



    Standard equipment
     Chuck key S13------------------------1 pc. (HP2032 only)
     Key holder 12-------------------------1 pc.(HP2032 only)
     Depth gauge---------------------------1 pc.
     Plastic carrying case------------------1 pc.
     [Note] The standard equipment may differ from country to country.

    Optional accessories
     T.C.T. Hammer Bit 5.0-70 ~19.0-220
     Hole Saw Ass'y 79mm, 95mm
     Blow out bulb 64

    Features and benefits
     Strong aluminum Gear housing and cam housing
Features    and benefits

                               Strong aluminum Gear housing
                               and Cam housing




Repair
Procedures other than listed below are the same as for HP2030
*Removal of cam B
To take cam apart from cam housing for the sake of recycle, etc., remove the cam with a
slotted driver as shown in the figure. Use repair tool "IR-020" to remove cam A.




                            Slotted driver


                                Com housing
   Wiring diagram
                                                                       Black
                                                                       Black                             Field

                                                                                White
       Power supply coad                          Switch
                                    2                                Purple
                               C2
                                                   3       2
                                        M2
                                             M1


                                    1
                                             C1    1       4

                           Black              Black             Orange


                                                       Black
             Transparent
                              Noise suppressor


           Ground to the field steel plate.

     *Noise suppressor or suppressor without earth wire will not be used for certain countries.
      Noise suppressor may differ from country to country.




   Putting lead wires into motor housing

                                                                                   Pass 'capacitor grounding
                                                                                   wire' inside the rib.
                                                                       Rib
                                                                                                 Rib


                      Brush holder lead wire                                                             Pass black lead wire
                      (Orange)                                                                           inside the rib.


Pass field lead wire (white) as shown in the                                                               Pass field lead wire (black) as shown in the
figure. Contain 'grounding wire' of noise                                                                  figure. Contain 'black lead wire' and 'brush
suppressor and 'brush holder lead wire                                                                     holder lead wire (purple)' in the lead holder.
(purple)' in the lead holder.                                                                              Brush holder lead wire (purple) should be
('Grounding wire' of noise suppressor should                                                               under the black lead wire.
be under the 'brush holder lead wire'.)




                                    Field lead wire
                                    (white)                                                             Field lead wire
                                                                                                        (black)
                              Grounding wire of
                              noise suppressor
                                                               Rib            Lead wire            Brush holder lead wire
                                                                              (black)              (purple)
                                                  Pass black lead
                                                  wire inside the rib.


     [Note] Connect wires as same as this description even if the noise suppressor is not used.
Putting away lead wires into handle




          Pass 'black lead wire' and
          'grounding wire of noise
          suppressor' between boss
          and bearing box.



              Contain lead wires
              in thr lead holder




         Noise suppressor




 [Note] Contain wires as same as this description even if the noise suppressor is not used.
