Image preview - the first page of the document
>> Download HP2040-TE documenatation <<
Text preview - extract from the document
T ECHNICAL INFORMATION
Models No. HP2040
New Tool
Description 20mm 2-Speed Hammer Drills
CONCEPTION AND MAIN APPLICATIONS 364mm(14-3/8")
Model HP2040/HP2041/HP2042 are upgraded and 2-speed
versions of the existing Model HP1500.
Its benefits are;
207mm(8-1/8")
*Less vibration toward hands
*Less noise
*More efficiency
Speed Reversing direction Width 66mm(2-5/8")
Model Drill chuck
Control of rotation
HP2040 Conventional(Keyed) Yes Yes
HP2041 Keyless Yes Yes
HP2042 Conventional(Keyed) No No
Specifications
Continuous Rating (W)
Voltage (V) Current (A) Cycle (Hz) Max. Output(W)
Input Output
100 6.8 50/60 650 300 500
120 6.0 50/60 650 300 500
220 3.1 50/60 650 300 500
230 3.0 50/60 650 300 500
240 2.8 50/60 650 300 500
No load speed Rotations HP2040,HP2041 L:0-950rpm H:0-2900rpm
per minute HP2042 L:950rpm H:2900rpm
Blows HP2040,HP2041 L:0-12400bpm H:0-37700bpm
per minute HP2042 L:12400bpm H:37700bpm
Drill chuck capacity 1.5-13mm(1/16-1/2")
Max.drilling capacities Concrete 20/13mm(3/4" / 1/2")
(L/H) Steel 13/8mm(1/2" / 5/16")
Wood 40/25mm(1-9/16" / 1")
Net weight 2.3Kg(5.1lbs)
Cord length 2.0m(6.6ft)
L:Low speed H: High speed
Standard equipment
Chuck Key S13(Model HP2040,HP2042 only)
Depth Gauge
Plastic Carrying Case
Features and benefits
1.Double insulated
2.See the attached sheets for more information.
The standard equipment for the tools shown may differ from country to country.
Less vibration toward hands
More efficiency
Handle shaped ergonomically
(H2040)
2-speed change lever Push button to change action mode
Rotation only
Very quiet
Rotation with hammering
No high frequency noise
Makita HP2040 104dB
