Image preview - the first page of the document
HP2041-TE


>> Download HP2041-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.            HP2041
                                                                                                         New Tool


     Description           20mm 2-Speed Hammer Drills

CONCEPTION AND MAIN APPLICATIONS                                                  364mm(14-3/8")
  Model HP2040/HP2041/HP2042 are upgraded and 2-speed
  versions of the existing Model HP1500.
  Its benefits are;




                                                                                                               207mm(8-1/8")
     *Less vibration toward hands
     *Less noise
     *More efficiency




                                        Speed        Reversing direction     Width 66mm(2-5/8")
     Model          Drill chuck
                                        Control          of rotation
    HP2040     Conventional(Keyed)       Yes                 Yes
    HP2041          Keyless              Yes                 Yes
    HP2042     Conventional(Keyed)        No                 No


  Specifications
                                                                Continuous Rating (W)
     Voltage (V)      Current (A)         Cycle (Hz)                                        Max. Output(W)
                                                               Input          Output
         100               6.8               50/60              650             300                500
         120               6.0               50/60              650             300                500
         220               3.1               50/60              650             300                500
         230               3.0               50/60              650             300                500
         240               2.8               50/60              650             300                500

    No load speed   Rotations         HP2040,HP2041         L:0-950rpm       H:0-2900rpm
                    per minute        HP2042                L:950rpm         H:2900rpm
                    Blows             HP2040,HP2041         L:0-12400bpm     H:0-37700bpm
                    per minute        HP2042                L:12400bpm       H:37700bpm
    Drill chuck capacity                                    1.5-13mm(1/16-1/2")
    Max.drilling capacities           Concrete              20/13mm(3/4" / 1/2")
    (L/H)                             Steel                 13/8mm(1/2" / 5/16")
                                      Wood                  40/25mm(1-9/16" / 1")
    Net weight                                              2.3Kg(5.1lbs)
    Cord length                                             2.0m(6.6ft)
    L:Low speed        H: High speed


  Standard equipment
   Chuck Key S13(Model HP2040,HP2042 only)
   Depth Gauge
   Plastic Carrying Case


  Features and benefits
   1.Double insulated
   2.See the attached sheets for more information.



 The standard equipment for the tools shown may differ from country to country.
Less vibration toward hands


                                                             More efficiency




                                                                      Handle shaped ergonomically

                       (H2040)




                                 2-speed change lever
                                                        Push button to change action mode
                                                           Rotation only
Very quiet                                                 Rotation with hammering
 No high frequency noise
    Makita HP2040 104dB
