Image preview - the first page of the document
HR160D-TE


>> Download HR160D-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.            HRl60D
                                                                                                            New Tool


     Description           Cordless Rotary Hammer

CONCEPTION AND MAIN APPLICATIONS                                                     296mm (11-5/8")
  Powerful 12-volt Cordless Rotary Hammer with 3-mode
  switching (Rotation only, Rotation with Percussion or
  Percussion only) Model HR160DH is sold with a battery
  cartridge 1201 but without a fast charger. Model
  HR160DWH includes a battery cartridge 1201 and a fast




                                                                                                                     232mm (9-1/8")
  charger DC1201.




  Specifications
   DC magnet motor (12 V)                     (12 V)
   Capacities        Concrete                 16mm(5/8")
                     Steel                    13mm(1/2")
                     Wood                     20mm(13/16")
   No load speed                              0-950 R/min.
   Blows per minute                           0-3,600
   Net weight                                 2.5Kg (5.5 lbs)


  Standard equipment
   Depth gauge, Grip, Battery cartridge 1201, Fast charger DC1201 (HRl60DWH only), Plastic carrying case
   (HRl60DWH only)


  Optional accessories
   Various sizes of tungsten-carbide tipped bits, Drill chuck assembly, Chuck key, Holder driver, Chisel adapter, Bull
   point, Cold chisel, Bit grease, Blow-out bulb, Dust cup, Dust extractor attachment, Taper shank adapter, Cotter


  Features and benefits
   1. Can be connected to Makita Dust Collector or Makita Vacuum Cleaner using a dust extractor attachment (optional
      accessory). So clean and dustless operation can be performed.
   2. Refer to the attached sheet for more information.




 The standard equipment for the tools shown may differ form country to country
                                               Forward/Reversing switch

     Built-in torque limiter protects operator
     by automatic disengagement whenever
     more than specified torque level is reached                                Powerful Makita motor



                                                                                               Slim body for easy grasp
 Easy bit installation/removal
 with handy change ring
 Accepts Makita genuine bits,
 SDS Plus bits and Hilti bits                                                                            Palm-fitted grasp for in-line
                                                                                                         hammer drilling action on the
                                                                                                         level




Both side grip and depth gauge
can be installed easily with
one clamp screw                                                Large, comfortable variable
                                                               speed trigger




             Large, comfortable side grip
             swings a full 360
