Image preview - the first page of the document
HR2410-TE


>> Download HR2410-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
     Models No.             HR2410
                                                                                                           New Tool


     Description            24 mm (15/16") Rotary Hammer

CONCEPTION AND MAIN APPLICATIONS                                                    350mm(13-3/4")
  Well balanced, lightweight rotary hammer with 2-mode
  switching mechanism for drilling only or hammer drilling.
  This rotary hammer is desigend mainly to drill holes
  12mm(15/32") and 14.5mm(9/16") in diameter for anchor




                                                                                                                197mm(7-3/4")
  bolts in concrete.




                                                                     Width: 70mm(2-3/4")


  Specifications
                                                                 Continuous Rating (W)
     Voltage (V)       Current (A)         Cycle (Hz)                                        Max. Output(W)
                                                                Input          Output
        100                6.5               50/60              620              210                 580
        115                6.2               50/60              680              250                 580
        200                3.6               50/60              680              250                 580
        220                3.3               50/60              680              250                 580
        230                3.1               50/60              680              250                 580
        240                3.0               50/60              680              250                 580

   Capacities        Concrete                  24mm(15/16")
                     Steel                     13mm(1/2")
                     Wood                      32mm(1-1/4")
   No load speed                               0-1,050R/min.
   Blows per minute                            0-4,900
   Net weight                                  2.3Kg(5.1 lbs)


  Standard equipment
   Depth Gauge, Side Grip, Plastic Carrying Case


  Optional accessories
   Various Sizes of Tungsten-carbide Tipped Bits, Drill Chuck assembly, Chuck Key, Holder Driver, Taper Shank
   Adapter, Cotter, Bit Grease, Blow-out Bulb, Dust Cup, Dust Extractor Attachment


  Features and benefits
   1. Double insulated
   2. Optional dust extractor attachment can be installed.
   3. Refer to the attached sheet for more information.




 The standard equipment for the tools shown may differ form country to country
                                          Built-in torque limiter protects
                                          operator by automatic disengagement
                                          whenever more than specified torque
                                          level is reached

Easy bit installation/removal
with handy change ring

                                                                                        Large, comfortable variable
                                                                                        speed trigger




                                      2-mode switching with change
                                      knob:Drilling only or
                                      Hammer drilling




                                                             Forward/Reversing switch
 Large, comfortable side grip
 swings a full 360
 Stays in place at desired position
 for safe, steady work
