Image preview - the first page of the document
HR2432-TE


>> Download HR2432-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
   Models No.                   HR2432
                                                                                                                     PRODUCT
                                                                                                                       P 1 / 21

   Description                                                                                             L
                                Rotary Hammer with Dust Extraction
                                                                                                               W
CONCEPT AND MAIN APPLICATIONS
   Model HR2432 has been developed as a successor                                                                            H
   to the current HR2430, and features the following advantages;
    * Self dust extraction system for clean operation
    * Bigger fan and bigger dust bag for efficient dust extraction
   All other outstanding features are the same as Model HR2450.
   They are;
    * 3 operation mode settings
       (Rotation only/ Rotation with hammering/ Hammering only)
    * Practical chisel angle positioning - 40 desired positions
      without using chisel adapter                                                                Dimensions: mm (")
                                                                                            Length (L)       407 (16)
                                                                                            Width (W)      120 (4-3/4)
                                                                                            Height (H)     220 (8-3/4)
 Specification
                                                                          Continuous Rating (W)
     Voltage (V)               Current (A)            Cycle (Hz)                                          Max. Output(W)
                                                                         Input           Output
          110                       7.5                50 / 60            780              280                     600
          120                       6.7                50 / 60            780              280                     600
          220                       3.7                50 / 60            780              280                     600
          230                       3.6                50 / 60            780              280                     600
          240                       3.4                50 / 60            780              280                     600
    No load speed : (min-1= rpm)                    0 - 1,000
    Blows per min, :(bpm=min-1)                     0 - 4,500
    Impact energy : J                                   2.2
    Variable switch                                    Yes
    Reverse switch                                     Yes
    Bit type                                        SDS-plus
    * Max. bit diameter : mm (")           24(15/16) [25(1") for USA]
    Protection from electric shock              Double insulation
                           Australia                 2.0 (6.6)
    Cord length : m ( ft ) Europe                   4.0 (13.1)
                           Other countries           2.5 (8.2)
    Net weight :Kg (lbs )                            3.0 (6.6)

 Standard equipment
    * Cap ................................... 1 pc.
    * Plastic carrying case ......... 1 pc.

   Note: The standard equipment for the tool shown above may vary from country to country.

 Optional       accessories
    * T.C.T. Hammer drill bit 4mm - 24mm                  * Drill chuck assembly                      * Taper shank adapter
                               (5/32" - 15/16")           * Scraper assembly                          * Cotter
                      for USA. up to 25mm(1")             * Dust cup 5 (for
