HR2220-TE


>> Download HR2220-TE documenatation <<

Text preview - extract from the document
T      ECHNICAL INFORMATION
        Models No.               HR2220
                                                                        New Tool


        Description            Rotary hammer

CONCEPTION AND MAIN APPLICATIONS
Adding the variable speed function to HR2210, this
hammer drill has a wider operational range and better
operability.




    Specifications
     Electric Motor               Series commutator motor
     Voltage                      100V
     Current                      5.5A
     Cycle                        50/60Hz
     Continuous rating inputs     520W
     Blows per minute             0-3000 strikes/min.
     No load speed                0-600 strikes/min.
     Overall length               365mm
     Net weight                   4.2kg
     Power supply cord            5m




    Equipment, Capacity, Handling, Dissembly/Assembly
     The same as those of HR2210.


    Features and benefits
    The number of strikes and the number of revolutions are variable,
    which enables easy drilling for fragile materials such as tiles.
    The other features and benefits are the same as those of HR2210.


    Start of production
    Model : February 5, 1981
    Model : September 20, 1980
