HR5001C-TE


>> Download HR5001C-TE documenatation <<

Text preview - extract from the document
T   ECHNICAL INFORMATION
      Models No.                HR5001C
                                                                                                                    New Tool
                                                                                                         118 (4-5/8")

      Description               50mm Rotary Hammer

CONCEPTION AND MAIN APPLICATIONS
  Model HR5001C is 50 mm rotary hammer for the SSDS-max bit




                                                                                                                               (11")
                                                                                                                                280
  designed as the sister version the existing Model HR4000C.
  Its brief benefits are;
   *Can achive the highest efficiency in this class.
   *Electrical speed control feature
      Variable speed
      Soft start
      Steady speed                                                                                610
                                                                                                 (24")

  Specifications
       Voltage(V)          Current(A)        Cycle(Hz)          Continuous Rating(W)         Max.Output(W)
                                                                 Input      Output
           100                 15               50/60            1450          460                 1400
           110                 15               50/60            1500          600                 1900
           120                 15               50/60            1500          600                 1900
           220                 7.7              50/60            1500          600                 1900
           230                 7.4              50/60            1500          600                 1900
           240                 7.1              50/60            1500          600                 1900

       No load speed       Rotations per minute         120 ~ 240rpm
                           Blows per minute             1100 ~ 2150bpm
       Bit type                                         SDS-max. shank
                                                        Diameter of shank : 18 mm(11/16'')
       Max.capacities        (Work : Concrete)          T.C.T.Bit:50mm(2")
                                                        Core bit : 160 mm(6-5/16")
       Net weight                                       10Kg(22bs)
       Cord length                                      5m(16.4ft)

  Standard equipment
   Grease Vessel ------------------1 pc.
   Plastic Carrying Case --------1 pc.
   Bar-type handle ---------------1 pc.
   D-type handle -----------------1 pc.


  Optional accessories
   T.C.T.Bit : 19(3/4"), 20(15/16"), 21.5(7/8"), 22(7/8"), 25(1"), 28(1-1/8"), 32(1-3/8"), 35(1-3/8"), 38(1-1/2")
   Bull point 280, 400      Cold chisel 25~280,25~400       Scaling chisel 50     Tile chisel 50
   Clay Spade      Core bit adapteer     D-type side handle
   Core bit : 20(15/16"), 30(1-3/16"), 35(1-3/8"), 40(1-9/16"), 45(1-3/4"), 54(2-1/8"), 65(2-9/16"),
              79(1-1/8"), 105(4-1/8") , 118(4-5/8")
   Grease Vessel(Bit grease,Hammer grease)         Depth Gauge       Safety Goggle


   Features and benefits
   1. Double insulated
   2. See the sheets attached for more information
    HR5001C                                   *:#Same features as HR4000C



     Efficiency
      The highest efficiency in this class.
                                                                       All enclosure is made of resin. *
                                                                        Even if the bit touches the electric wire
                                                                        inside the wall,an electrical shock may
                                                                        hardly hit on the operator.


    Push-to-strike system
    Bit does not jump arround.
    Efficiency and endurance                                              New torque limitter system
    are improved.                                                          Roller clutch system
                                        * Large change lever               (#HR4000C:Ball clutch system)
                                          Easy to change opeation mode
                                                                           for coping with the higher power,
                                          between "Hammering only"
                                                                           and for improvement of endurance.
                                          and "Rotation with hammerig"
  * For pointing job, you can use
     this toolholding barrel                                                      * Large trigger
                                                                                     No fatigue at finger after
     without feeling heat from barrel                                                long operation.
     by resin cover




      * One touch chuck
        By just inserting,
         the bit can be installed.
                                                                                                   Lamp will light off,when     *
                                                                                                   switch or power supply
                                                                                                   cord becomes defective.
* D-type handle ( Standard accessory)                                                                Lit during no defective.
  Bar-handle      ( Standard accessorry)
                                                                                                     Lamp will light up for   *
   Both handles can be fixed at any angle and
                                                                                                     indicating time for
   at any positions back/forth on the barrel.                                                        replacement of
   The D-type handle for hammering can be                                                            carbon brushes
   swiveled at 8 positions back/forth.                                                               It will light up about 8-hr
                                                                 Automatic cut-off                   before the carbon brush are
                                                                 carbon brush                        worn out.
                                                                 Carbon brushes can be              Power supply cord or *
                                                                 replaced without                   switch can be easily
                                                                                                    replaced.
                                                                 remove the rear cover.
                                                                                                    by removing two screws
                                                                                                    of handle cover.
          270mm                    200mm
     Holding power required when torque limiter operating
       Approx. 20 kgf         Approx. 29 kgf                                                Speed adjustable dial
       Makita #HR5001C        Bosch #GBH10DC                                           Light hammering or drilling
                                                    Longer life motor                  is easily performed
 * Large model plastic case
    (standard accessory)                             The thicness of the commutator is by setting lower speed.
    600 mm(23-5/8") bit. can be                      2 times of HR5000 .
    carried.                                         The varnish is coated on the armature
                                                     against dust.
Repair




 (1)     Removing Change lever ------------------------------ ------(Page 6 of 14)
 (2)     Install Change lever ------------------------------- ----------(Page 6 of 14)
 (3)     Replace the Armature ------------------------------- --------(Page 7 of 14)
 (4)     Disassembling the chuck --------------------------- -------(Page 8 of 14)
 (5)     Assembling the chuck ------------------------------- -------(Page 8 of 14)
 (6)     Removing Tool holderers --------------------------- ------(Page 8 of 14)
 (7)     Disassembling tool holders ------------------------- -------(Page 9 of 14)
 (8)     Assembling the tool holder A and B ----------------- -----(Page 9 of 14)
 (9)     Taking out Cylinder 40 ----------------------------- --------(Page 9 of 14)
 (10)    Assembling Piston, Rod and Crank shaft -------------- -(Page 10 of 14)
 (11)    Assembling Fluoride ring 28 on Impact bolt ---------- (Page 10 of 14)
 (12)    Assembling several parts in Crank housing ----------- (Page 11 of 14)
 (13)    Inserting T ool holders -------------------------------------(Page 11 of 14)
 (14)    Assembling Torque limiter complete -------------------(Page 12 of 14)
 (15)    Lublication ----------------------------------------- --------(Page 13 of 14)
