Image preview - the first page of the document
JR3020-TE


>> Download JR3020-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION                                                                                      New Tool


      Models No.                  JR3020
      Description              Recipro Saw

CONCEPTION AND MAIN APPLICATIONS
   Model JR3020 employs the most powerful motor in its class
                                                                                                  ")
   (1,020 W) and orbital cutting action mechanism for fast, smooth                         (18-1/4
                                                                                  463mm




                                                                                                                 168mm(6-5/8")
   cutting in various materials. You can select a cutting action
   suitable for your work using the one-touch lever : straight line,
   small orbit, medium orbit or large orbit cutting actions.




                                                                            92mm(3-5/8")


  Specifications
                                                                Continuous Rating (W)
     Voltage (V)       Current (A)         Cycle (Hz)                                         Max. Output(W)
                                                               Input          Output
         100               10.7              50/60             1,020            580                    1,200
         115               9.3               50/60             1,020            580                    1,200
         200               5.4               50/60             1,020            580                    1,200
         220               4.9               50/60             1,020            580                    1,200
         230               4.7               50/60             1,020            580                    1,200
         240               4.5               50/60             1,020            580                    1,200

                                  Pipe         90 mm (3-1/2")
   Max.Cutting Capacity
                                  Wood         90 mm (3-1/2")
   Length of Stroke                            30 mm (1-3/16")
   Strokes per Minute                          0 - 2,500
   Net Weight                                  3.8 kg (8.4 lbs)


  Standard equipment
   Recipro Saw Blade No.21, No. 22, No. 23, Hex Wrench, Plastic Carrying Case


  Optional accessories
   Recipro Saw Blade No. 21, No. 22, No. 24 (for steel), Recipro Saw Blade No.23, 23B (for wood)


  Features and benefits
   1.Double insulated for operator safety
   2.See the attached sheet for more information.




 The standard equipment for the tools shown may differ form country to country
                                                                Lock Button                       Speed Control Knob
                                                                Lets you operate tool without     Pull trigger all the way to be
          Comfortable Rubber Cover
                                                                having to keep your finger on     able to change speed (rpm)
          (Barrel)
                                                                the trigger.




                                                                                                                       Large easy-to-Operate
                                                                                                                        Trigger Switch
                                                                                                                       (Variable Speed)




Shoe Fastening Lever
Easy adjustment without tools



                           Orbit Action Setting (Lever)
                           Just set the one-touch lever to
                           the desired orbital action settihg
                                                                                   Anti-Vibration Handle
