Image preview - the first page of the document
JS1600-TE


>> Download JS1600-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION
      Models No.           JS1600
                                                                                                          New Tool


     Description           MAKITA Shear

CONCEPTION AND MAIN APPLICATIONS
  It is developed to expand the metal working market with the purpose
  for high-speed cut of soft steel plates, tinplates and stainless
  plates, etc. We tried to make it as compact as possible and
  make it easier for use because of applying a lever type switch.
  Moreover, we paid attention to safety such as the protector and
  the double insulation structure, etc.



  Specifications
       Voltage (V)              Current (A)              Cycle (Hz)               Continuous rating input(W)
          100                      3.2                    50/60                             300

   Strokes per minute(/min)                   40000
   Capacity(mm)          Soft steel plate     1.6mm
                         Stainless plate      1.2mm
   Overall length(mm)                         230mm
   Net Weight(kg)                             1.7kg
   Power supply cord(m)                       2.0m


  Standard equipment
   Hexagonal stick spanner--- 1piece
   Wrench holder 3-7---1piece
   Special accessories


  Optional accessories
   Shear blade


  Features and benefits
   1. As we pursued easy-use and designed to be small and light, you can use for long hours without feeling
      exhaustion and are able to swing round (such as curved line cutting) easily.
   2. The upper shear blades and the lower ones are in common in use, of which 8 corners can be used for cutting
      respectively. Also, since we adjusted the clearance of blades as 0.1mm-0.2mm,you can use without adjusting to
      the extent of soft steel plates of 1.6mm and stainless plates of 1.2mm.
   3. As the Maximum Capacity Gauge is attached, you are able to operate without any worrying.
   4. Owing to application of lever type switch, you can operate switches by one hand easily.
   5. The protector is provided to safeguard your hands from cut pieces during operation, and you can work safely.
   6. You need not earth without worrying, because the machine has an electrically safe double-insulation structure




 The standard equipment for the tools shown may differ form country to country.
Capacity
                                                    Table
