Image preview - the first page of the document
JS1660-TE


>> Download JS1660-TE documenatation <<

Text preview - extract from the document
T    ECHNICAL INFORMATION                                                                                     New Tool


       Models No.                JS1660
       Description               MAKITA 1.6 mm Straight shear

CONCEPTION AND MAIN APPLICATIONS                                              72
   This is the model-changed version of the JS1650, wherein the
   step difference is made on the side blade to minimize the
   contact range between the cutting material and the side blade,




                                                                             80
   thereby the cutting material cannot be damaged so easily. Other                              304

   features are same as JS1650.


  Specifications
                                                             Consumed               Rated
     Voltage(V)         Current(A)           Cycle (Hz)                                         Max. output(W)
                                                             power(W)             output(W)
        100                2.7                50/60            260                   145              280
        115                2.3                50/60            260                   145              280
        200                1.4                50/60            260                   145              280
        220                1.2                50/60            260                   145              280
        230                1.2                50/60            260                   145              280
        240                1.1                50/60            260                   145              280

   No Load Speed          No. of striking       4500/min
   Max. cutting plate     Soft steel plate      1.6mm
   thickness(mm)          Stainless plate       1.2mm
   Net Weight                                   1.4kg
   Cord length(m)                               2.5m

  Standard equipment
   Hex. wrench 3
   Wrench holder
   Thickness gauge

  Optional accessories
   Side blade R
   Side blade L
   Center blade

  Features and benefits
   1. The step difference made on the side blade will minimize the contact
      range(see ''a'' shown on right figure)between the cutting material and the
      side blade, thereby the cutting material cannot be damaged so
      easily.(Other features shown below are same as JS1650.)The shape of                  a             a
      side blade                                                                             (JS1650)      (JS1660)
   2. The both blades cutting system may not deform the plate after cutting unlike the one blade type shear.
   3. The cutting chips can be discharged only in one direction, thereby enabling high working efficiency in safety.
   4. The edge of the machine is well designed so that the cutting section can be easily seen.
   5. The C-type channel can be cut.
   6. The burr production can be minimized through adjusting the clearance between blades depending on the plate
      thickness.
   7. The slide type switch is mounted on the center of the machine so that it can be handled by whichever hand of left
      or right hand.
   8. The light weight(1.4 kg) enables to operate for a long time.

 The standard equipment for the tools shown may differ form country to country.
             Capacity
    (1) Thickness of the cutting material and the                                           (2) Thickness of the cutting material and
(m/min.) cutting speed                                                                    (A) the load current value(in 100V)
     9
                                                                                          3.0
                   8
                                               Soft steel plate
                   7
   Cutting speed




                                                                                                      Stainless plate                 Soft steel plate




                                                                                Current
                           Stainless plate
                   6                                                                      2.0
                   5
                   4
                                                                                          1.0
                       0
                                        0.5      1.0              1.5                                         0.5         1.0             1.5
                                                       1.2           1.6 (mm)                                                   1.2          1.6 (mm)
                       Thickness of cutting material                                            Thickness of cutting material




             Repair
                   Same as JS1650.
